KEMET C276CC35300AA0J Power Start Capacitor
This low-voltage capacitor series is designed for reliable start-up and operational efficiency in single-phase electric motors, such as air-fans, pumps, and circulators. Conforming to IEC 60252 standards, these electrolytic capacitors feature polypropylene dielectric, self-healing plates, and are suitable for continuous or intermittent service at rated voltages up to 470V. Available with various mounting options, they provide excellent performance, high safety standards, and a long operational life, making them ideal for various industrial and domestic applications.
KEMET C276CC35300AA0J Power Start Capacitor Specifications:
- Capacitance: 10uF
- Rated Voltage: 470V~
- Maximum voltage: 517V (1.10 x Rated Voltage)
- Operating Temperature Range: -25°C to +85°C
- Storage Temperature Range: -40°C to +90°C
- Life Expectancy: 10,000 hours at 470V and 85°C, 30,000 hours at 420V and 85°C
- Capacitance Tolerance: +5%
- Dielectric Material: Polypropylene
- Case Material: Polypropylene with self-extinguishing features V2 (UL94)
- Mounting: Any position
- Leakage clearance: > 5mm in air under voltage
- Test Voltage: 2Vn terminal-to-terminal for 2s, 2000V terminal-to-case for 2s
- Safety Class: PO
- Max Altitude: 2000 meters
- Approval Standards: IEC 60252, EN 60252, UL 810
Buy the Buy KEMET Capacitor Part Number C276CC35300AA0J Online
Purchase the KEMET C276CC35300AA0J capacitor online today and enjoy fast delivery, optimal performance, and excellent reliability. This high-quality capacitor is designed for motor start applications such as pumps, fans, and circulators, conforming to stringent IEC standards. With polypropylene dielectric and self-healing plates, it offers excellent endurance at rated voltages up to 470V and a temperature range from -25°C to +85°C. Ideal for industrial and residential use, this capacitor guarantees long operational life, safety compliance, and versatile mounting options for guaranteed performance and peace of mind.
Buy KEMET C276CC35300AA0J high-performance motor start capacitor now and ensure reliable operation with long service life up to 30,000 hours at 420V.
Frequently Asked Questions
Where can I buy KEMET C276CC35300AA0J?
You can click on the BUY or RFQ button to purchase C276CC35300AA0J from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part C276CC35300AA0J?
You can download the C276CC35300AA0J datasheet or visit the KEMET website for support.
Who is the manufacturer of C276CC35300AA0J?
KEMET
