KEMET C315C330J1G5TA 33pF Ceramic Capacitor
The KEMET GoldMax 300 Comm C0G capacitor (C315C330J1G5TA) is a high-performance, multilayer ceramic capacitor designed for a wide range of commercial applications. Its C0G dielectric provides excellent stability over temperature, while the radial lead configuration allows for easy integration into various circuit designs. This capacitor is RoHS compliant and offers a wide temperature range (-55°C to +125°C), making it suitable for demanding environments. It's ideal for decoupling, filtering, and timing circuits in consumer electronics, industrial equipment, and automotive applications.
KEMET C315C330J1G5TA 33pF Ceramic Capacitor Specifications:
- Series: GoldMax 300 Comm C0G
- Style: Radial
- Description: Commercial Standard
- RoHS: Yes
- Termination: Tin
- AEC-Q200: No
- Halogen Free: Yes
- Capacitance: 33 pF
- Measurement Condition: 1 MHz 1.0Vrms
- Capacitance Tolerance: 5%
- Voltage DC: 100 VDC
- Dielectric Withstanding Voltage: 250 VDC
- Temperature Range: -55/+125°C
- Temperature Coefficient: C0G
- Capacitance Change with Reference to +25°C and 0 VDC Applied(TCC): 30PPM/C, 1MHz 1.0Vrms
- Dissipation Factor: 0.1% 1 MHz 1.0Vrms
- Aging Rate: 0% Loss/Decade Hour
- Insulation Resistance: 100 GOhms
- L: 3.81mm MAX
- H: 3.14mm MAX
- T: 2.54mm MAX
- S: 2.54mm +/-0.78mm
- LL: 7mm MIN
- F: 0.51mm +0.1/-0.025mm
- Packaging: Bulk, Bag
- Packaging Quantity: 500
