KEMET C320C475K3N5TA Ceramic Capacitor
The GoldMax 300 X8L HT150C is a high-quality ceramic capacitor designed for reliable performance in industrial and electronic applications. Featuring a capacitance of 4.7 µF with 10% tolerance and rated for 25 VDC, it offers excellent stability from -55°C to +150°C. Its X8L dielectric ensures stable capacitance over a wide temperature range. Compact with a lead spacing of 2.54mm, it is RoHS compliant, halogen free, and suitable for commercial standard use, making it ideal for electronic circuits requiring dependable capacitance and temperature resilience.
KEMET C320C475K3N5TA Ceramic Capacitor Specifications:
- Capacitance: 4.7 µF
- Capacitance Tolerance: 10%
- Voltage DC: 25 VDC
- Dielectric Withstanding Voltage: 625 VDC
- Temperature Range: -55°C to +150°C
- Temperature Coefficient: X8L
- Lead Spacing: 2.54mm ±0.78mm
- Dimensions: Length 7mm min, Width 0.51mm +0.1/-0.025mm
- Dissipation Factor: 2.5% at 1 MHz
- Insulation Resistance: 210 MΩ
- Packaging: Bulk, Bag
- Quantity per package: 500 units
- RoHS compliant: Yes
- Halogen Free: Yes
- Termination: Tin-plated
- Reliability: Aging rate 3% loss/decade hour
Buy the KEMET C320C475K3N5TA – Reliable Ceramic Capacitor for Industrial Applications
Purchase the KEMET C320C475K3N5TA ceramic capacitor online today and ensure your electronic devices operate reliably under demanding conditions. This high-quality component offers 4.7 µF capacitance with a voltage rating of 25 VDC, suitable for industrial applications requiring stability from -55°C up to +150°C. Its X8L dielectric provides excellent temperature stability, while the RoHS compliance and halogen-free design meet modern environmental standards. Ideal for compact electronic circuits, this bulk-packaged capacitor delivers consistent performance and long-term reliability for your engineering needs.
Order your KEMET Series C320C475K3N5TA ceramic capacitor today and enhance your electronic projects with dependable, high-temperature performance and stable operation.
Frequently Asked Questions
Where can I buy KEMET C320C475K3N5TA?
You can click on the BUY or RFQ button to purchase C320C475K3N5TA from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part C320C475K3N5TA?
You can download the C320C475K3N5TA datasheet or visit the KEMET website for support.
Who is the manufacturer of C320C475K3N5TA?
KEMET
