KEMET C44PMGR6166RASJ Power Filter Capacitor
The C44PMGR6166RASJ is a high-capacity metallized polypropylene AC filter capacitor designed for single-phase PFC applications. With a capacitance of 166 uF and a voltage rating of 480 VAC / 1100 VDC, it ensures reliable performance across wide temperature ranges from -25°C to +70°C. Featuring threaded M10 studs for easy mounting, its thermal resistance is 5°C/W, and it has a low ripple current of 55 Amps at 10kHz. The compact dimensions are 85mm diameter and 197mm length, making it suitable for industrial power filtering applications requiring robust build quality and efficiency.
KEMET C44PMGR6166RASJ Power Filter Capacitor Specifications:
- Capacitance: 166 uF
- Capacitance Tolerance: 5%
- Voltage AC: 480 VAC
- Voltage DC: 1100 VDC
- Dimensions: Diameter 85mm ±0.5mm, Length 197mm ±2mm
- Temperature Range: -25°C to +70°C
- Rated Temperature: 70°C
- Mounting: Bolt M12x16
- Dielectric: Metallized Polypropylene
- Features: Single Phase PFC, RoHS compliant with exemptions
- Thermal Resistance: 5°C/W
- Ripple Current: 55 Amps at 10kHz
- Inductance: 173 nH
- Resistance: 1.4 mOhms at 10kHz
Buy the KEMET Series C44P-R AC Filter Capacitor: C44PMGR6166RASJ
Secure your power systems with the KEMET power filter capacitor designed for high-capacity industrial applications. Featuring 166 microfarads capacitance, 480 volts AC rating, and durable metallized polypropylene dielectric, this capacitor ensures efficient power filtering and long-term stability. Its M12 bolt mounting and compact size make installation easy and reliable. With a temperature range from -25°C to +70°C, low ESR of 1.4 milliohms, and high ripple current capacity of 55 Amps, it provides peak performance for demanding electrical environments.
Buy KEMET C44PMGR6166RASJ now and experience unmatched reliability and performance in industrial power filtering with high capacitance and robust construction.
Frequently Asked Questions
Where can I buy KEMET C44PMGR6166RASJ?
You can click on the BUY or RFQ button to purchase C44PMGR6166RASJ from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part C44PMGR6166RASJ?
You can download the C44PMGR6166RASJ datasheet or visit the KEMET website for support.
Who is the manufacturer of C44PMGR6166RASJ?
KEMET
