KEMET C44PXGR5470RASK Film Capacitor
The C44P-R series film capacitor is designed for AC filtering and power factor correction applications, featuring metallized polypropylene dielectric and a can-style design. It offers a capacitance of 47 uF with 10% tolerance, rated for 1000 VAC and 2300 VDC. The capacitor operates effectively within a temperature range of -25°C to +70°C and includes threaded M10 studs for secure mounting. Its compact dimensions, robust construction, and thermal resistance make it suitable for various industrial and electronic filtering applications, ensuring reliable performance and compliance with RoHS standards.
KEMET C44PXGR5470RASK Film Capacitor Specifications:
- Capacitance: 47 uF
- Capacitance Tolerance: 10%
- Voltage AC: 1000 VAC
- Voltage DC: 2300 VDC
- Temperature Range: -25°C to +70°C
- Rated Temperature: 70°C
- Max dVidt: 85 V
- Resistance: 1.414 mOhms (LOkHz)
- Ripple Current: 45 Amps (LOkHz, 40°C)
- Inductance: 170 nH
- Dimensions: D 85mm ±0.5mm, L 247mm ±2mm, W 24mm ±1mm, S 35mm ±1mm, WI 45mm ±1mm
- Mounting: Bolt M12x16
- Packaging: Bulk, Bag
- Dielectric: Metallized Polypropylene
- Features: Single Phase PFC
- RoHS: Compliant with exemptions
- Lead: Threaded Studs M10
- Thermal Resistance: 4.7°C/W
Buy the KEMET Series C44P-R Film Capacitor: C44PXGR5470RASK
Purchase the KEMET Series C44P-R film capacitor online for your power filtering and correction needs. With a capacitance of 47 uF, 1000 VAC rating, and robust polypropylene dielectric, this component ensures high-performance operation in industrial, electronic, and power applications. Its compact size, threaded M10 studs for secure mounting, and thermal resistance make it ideal for demanding environments. Order online now to get this reliable, RoHS-compliant capacitor delivered quickly and support your project’s efficiency and durability.
Order your KEMET Series C44P-R film capacitor today and ensure reliable power filtering and power factor correction for your electronic or industrial projects.
Frequently Asked Questions
Where can I buy KEMET C44PXGR5470RASK?
You can click on the BUY or RFQ button to purchase C44PXGR5470RASK from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part C44PXGR5470RASK?
You can download the C44PXGR5470RASK datasheet or visit the KEMET website for support.
Who is the manufacturer of C44PXGR5470RASK?
KEMET
