KEMET C44UHGT6800M82K high-capacity film capacitor
The C44UHGT6800M82K is a high-capacity film capacitor featuring metallized polypropylene dielectric, designed for DC link applications and energy storage. It offers a capacitance of 800 uF with a tolerance of 10%, rated at 600 VDC. Its robust construction includes screw terminals M6 and a bolt mounting system, suitable for industrial and power electronics applications. The capacitor operates efficiently within a temperature range of -40°C to +85°C, with a thermal resistance of 6.4°C/W. It complies with RoHS exemptions and features a weight of approximately 960 grams, making it ideal for demanding power filtering and energy storage tasks.
KEMET C44UHGT6800M82K high-capacity film capacitor Specifications:
- Capacitance: 800 uF
- Capacitance Tolerance: 10%
- Rated Voltage: 600 VDC
- Temperature Range: -40°C to +85°C
- Dimensions: D 85mm +2mm, L 114.5mm +/-2mm, La 116mm +/-2mm
- Weight: approx. 960 grams
- Mounting: Bolt M12x16
- Insulation Resistance: 40 MOhms
- Thermal Resistance: 6.4°C/W
- Ripple Current: 57 Amps at 10 kHz 40°C
- Inductance: 50 nH
- Resistance: 1.4 mOhms at 10 kHz
- RoHS Compliant with Exemptions
- Lead Terminals: Screw M6
- Dielectric Material: Metallized Polypropylene
Buy the KEMET C44UHGT6800M82K – Reliable Power Capacitor for Industrial Applications
Secure your power filtering and energy storage needs with the high-capacity C44UHGT6800M82K film capacitor. Featuring metallized polypropylene dielectric, 800 uF capacitance, and rated at 600 VDC, it is perfect for demanding industrial and power electronics applications. Easy to mount with M6 screw terminals, it offers excellent thermal stability, low ESR, and high ripple current capabilities. Purchase online today to ensure reliable performance in your power systems, backed by quality construction and RoHS compliance for safe, efficient operation.
Buy KEMET C44UHGT6800M82K now and experience unmatched reliability and high-performance energy storage for industrial applications.
Frequently Asked Questions
Where can I buy KEMET C44UHGT6800M82K?
You can click on the BUY or RFQ button to purchase C44UHGT6800M82K from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part C44UHGT6800M82K?
You can download the C44UHGT6800M82K datasheet or visit the KEMET website for support.
Who is the manufacturer of C44UHGT6800M82K?
KEMET
