KEMET C44UHGT6900M83K DC Link Capacitor
The KEMET C44U-M series film metallized polypropylene capacitor is designed for DC link applications, providing reliable energy storage and filtering. With a capacitance of 900 microfarads and a voltage rating of 600 VDC, this can-style capacitor features screw terminals M6 for secure mounting. It operates effectively within a temperature range of -40°C to +85°C and offers low resistance of 1.6 milliohms at 10kHz, ensuring efficient performance in power conversion systems and industrial electronics. Its compact dimensions and thermal resistance of 5.8°C/W make it suitable for demanding environments.
KEMET C44UHGT6900M83K DC Link Capacitor Specifications:
- Capacitance: 900 uF
- Capacitance Tolerance: 10%
- Voltage DC: 600 VDC
- Temperature Range: -40°C to +85°C
- Rated Temperature: 75°C
- Dimensions: Diameter 88mm +0.5mm, Length 124.5mm +/-2mm, Width 32mm +/-0.3mm
- Terminal Type: Screw terminals M6
- Insulation Resistance: 30 MOhms
- Ripple Current: 56 Amps (at 40°C)
- Leakage Current: Max 4V
- Inductance: 50 nH
- Thermal Resistance: 5.8°C/W
- Packaging: Bulk, Bag
- Weight: 102 grams
Buy the KEMET Series C44U-M DC Link Capacitor: C44UHGT6900M83K
Purchase the KEMET C44U-M series DC link capacitor online today to ensure your power systems operate smoothly and efficiently. This 900 microfarad, 600-volt device delivers exceptional performance for industrial, energy storage, and filtering applications. Its robust construction, screw terminals, and wide temperature tolerance make it suitable for demanding environments. With easy online ordering, you can quickly upgrade your electronics with a reliable, high-quality capacitor that offers low resistance, excellent thermal management, and long-term durability. Get yours now for enhanced system performance!
Buy KEMET C44UHGT6900M83K now and experience unmatched reliability and performance with efficient energy storage and filtering capabilities.
Frequently Asked Questions
Where can I buy KEMET C44UHGT6900M83K?
You can click on the BUY or RFQ button to purchase C44UHGT6900M83K from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part C44UHGT6900M83K?
You can download the C44UHGT6900M83K datasheet or visit the KEMET website for support.
Who is the manufacturer of C44UHGT6900M83K?
KEMET
