KEMET C44UOGT6450M82K Film Capacitor
The C44UOM series capacitor by KEMET is a high-performance metallized polypropylene film capacitor designed for DC linking and energy storage applications. With a capacitance of 450 uF and a voltage rating of 900 VDC, it is ideal for power electronic systems requiring reliable filtering and energy storage. Featuring screw terminals M6 and a compact size with dimensions of approximately 85mm in diameter and 114.5mm in length, it offers a temperature range of -40°C to +85°C, low equivalent series resistance, and a maximum ripple current suitable for industrial power applications. Suitable for demanding environments, it meets RoHS standards and is available in bulk packaging.
KEMET C44UOGT6450M82K Film Capacitor Specifications:
- Capacitance: 450 uF
- Voltage DC: 900 VDC
- Temperature Range: -40°C to +85°C
- Dimensions: Diameter approximately 85mm, length approximately 114.5mm
- Mounting: Bolt - M12x16
- Insulation Resistance: 70 MOhms
- Capacitance Tolerance: 10%
- D1: 88mm ±0.5mm
- Weight: 960 grams
- Rated Temperature: 75°C
- L: 116mm ±2mm
- S: 32mm ±0.3mm
- Ripple Current: 51 Amps at 10kHz/40°C
- Leakage Resistance: 1.8 mOhms at 10kHz
- Inductance: 50 nH
- Thermal Resistance: 6.4°C/W
- RoHS Compliant with Exemptions
- Lead Terminals: M6 screw
- Certification: Not specified for AEC-Q200
Buy the KEMET C44U2013 Reliable Capacitor for Industrial Applications
Purchase the KEMET C44U capacitors online today for reliable energy storage and power filtering solutions. Featuring 450 uF capacitance rated at 900 VDC, these high-performance film capacitors are suited for demanding industrial power systems. They offer a temperature range from -40°C to +85°C, low equivalent series resistance, and robust screw terminals for secure mounting. Ideal for DC link applications, they comply with RoHS standards and are available in bulk packaging. Ensure your power electronics are equipped with quality components—order now for fast delivery and superior performance.
Get KEMET C44U online today—designed for high-capacity energy storage and power filtering in industrial systems.
Frequently Asked Questions
Where can I buy KEMET C44UOGT6450M82K?
You can click on the BUY or RFQ button to purchase C44UOGT6450M82K from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part C44UOGT6450M82K?
You can download the C44UOGT6450M82K datasheet or visit the KEMET website for support.
Who is the manufacturer of C44UOGT6450M82K?
KEMET
