KEMET C44UQGT6240M81K High-Voltage Film Capacitor
The KEMET C44UQGT6240M81K is a high-performance film capacitor featuring metallized polypropylene dielectric, designed for DC link applications. With a capacitance of 240 uF ±10% and a voltage rating of 1100 VDC, this can-style component offers reliable energy storage and filtering. It features screw terminal mounting with M6 screws, has a thermal resistance of 7.1°C/W, and weighs approximately 880 grams. Suitable for demanding electrical environments, it operates within a temperature range of -40°C to +85°C and complies with RoHS standards, making it ideal for industrial power systems and filtering circuits.
KEMET C44UQGT6240M81K High-Voltage Film Capacitor Specifications:
- Capacitance: 240 uF
- Tolerance: 10%
- Voltage DC: 1100 VDC
- Temperature Range: -40°C to +85°C
- Dimensions: D 85mm +2mm, L 99.5mm +/-2mm, La 101mm +/-2mm
- Mounting: Bolt M12x16
- Insulation Resistance: 130 MOhms
- Leakage Current: Max 12 V
- Ripple Current: 48 Amps at 10kHz, Peak 2905 Amps
- Inductance: 45 nH
- Resistance: 1.8 mOhms at 10kHz
- Thermal Resistance: 7.1°C/W
- Component Weight: 880 grams
- Packaging: Bulk, Bag, Quantity: 5
- RoHS Compliant: Yes
- Material: Metallized Polypropylene
- Style: Can
- Lead Terminals: M6 Screw
- Rated Temperature: 75°C
Buy the KEMET Series C44U-M Film Capacitor: C44UQGT6240M81K
Buy your KEMET C44UQGT6240M81K high-voltage film capacitor online today to ensure your electrical systems operate efficiently and reliably. With a capacitance of 240 uF and a DC voltage rating of 1100 V, this can-style component is perfect for industrial power filtering, energy storage, and DC link applications. Its robust M6 screw terminals provide secure mounting, while its metallized polypropylene dielectric offers excellent electrical performance and durability. Compatible with various power electronics and industrial equipment, this capacitor guarantees consistent quality and compliance with RoHS standards, making it a dependable choice for demanding projects and professional deployments.
Order your KEMET Series C44UQGT6240M81K film capacitor today and enhance your power filtering and energy storage systems with reliable performance.
Frequently Asked Questions
Where can I buy KEMET C44UQGT6240M81K?
You can click on the BUY or RFQ button to purchase C44UQGT6240M81K from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part C44UQGT6240M81K?
You can download the C44UQGT6240M81K datasheet or visit the KEMET website for support.
Who is the manufacturer of C44UQGT6240M81K?
KEMET
