KEMET C44UQGT6700M52K Power Capacitor
This metallized polypropylene film capacitor is designed for high-voltage DC applications, offering 700 uF capacitance at 1100 VDC with a 10% tolerance. It features screw terminal mounting M6, can dimensions of approximately 116mm by 153mm, and operates within a temperature range of -40°C to +85°C. Its low inductance of 55 nH and ripple current capacity of 4 Amps make it ideal for DC filtering and energy storage in industrial and power electronics applications. Certified RoHS compliant, it provides reliable performance and thermal resistance of 3.2 CW.
KEMET C44UQGT6700M52K Power Capacitor Specifications:
- Capacitance: 700 uF
- Voltage DC: 1100 VDC
- Capacitance Tolerance: 10%
- Temperature Range: -40°C to +85°C
- Dimensions: D 116mm ±2mm, L 153mm ±2mm, s 50mm ±0.3mm
- Mounting: Bolt M6
- Insulation Resistance: 40 MOhms
- Ripple Current: 4 Amps (LOkHz 400)
- Inductance: 55 nH
- Rated Temperature: 75°C
- Thermal Resistance: 3.2 CW
- Resistance: 1.7 mOhms (10kHz)
Buy the Buy KEMET C44UQGT6700M52K Part Number C44UQGT6700M52K Online
Enhance your power electronics with the high-performance KEMET Capacitor C44UQGT6700M52K. This 700 uF, 1100 VDC metallized polypropylene film capacitor is designed for demanding applications such as DC filtering, energy storage, and industrial power systems. Its robust construction with screw terminals M6 and operating temperature range of -40°C to +85°C guarantees reliable performance. Certified RoHS compliant, it offers low inductance, high insulation resistance, and thermal durability, making it a vital component for high-voltage power management solutions. Purchase online today for superior electrical performance and peace of mind.
Buy KEMET C44UQGT6700M52K now and ensure high reliability with efficient energy storage and filtering in your power systems.
Frequently Asked Questions
Where can I buy KEMET C44UQGT6700M52K?
You can click on the BUY or RFQ button to purchase C44UQGT6700M52K from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part C44UQGT6700M52K?
You can download the C44UQGT6700M52K datasheet or visit the KEMET website for support.
Who is the manufacturer of C44UQGT6700M52K?
KEMET
