KEMET C44USGT6165M83K High Voltage Film Capacitor
The C44U-M is a high-voltage metallized polypropylene film capacitor designed for DC filtering and energy storage applications. With a capacitance of 165 uF at 10% tolerance and a rated voltage of 1500 VDC, it is suitable for demanding power electronics and industrial environments. The can-style design features screw terminals M6 for reliable mounting, with a thermal resistance of 5.8°C/W. Its dimensions are approximately 85mm in diameter and 124.5mm in length, and it operates within a temperature range of -40°C to +85°C, ensuring robustness in varied conditions.
KEMET C44USGT6165M83K High Voltage Film Capacitor Specifications:
- Capacitance: 165 uF
- Capacitance Tolerance: 10%
- Voltage DC: 1500 VDC
- Temperature Range: -40°C to +85°C
- Dimensions: Diameter 85mm +2mm, Length 124.5mm +/-2mm
- Mounting: Bolt M12x16
- Insulation Resistance: 180 MOhms
- Thermal Resistance: 5.8°C/W
- Inductance: 50 nH
- Ripple Current: 40 Amps at 10kHz, 2045 Amps Peak
- Resistance: 3.2 mOhms at 10kHz
- Max dVidt: 12 Vus
- Packaging: Bulk, Bag
- Component Weight: 10209 grams
- RoHS Compliance: Yes, with exemptions
- Lead Terminals: M6 screw terminals
Buy the Buy KEMET C44USGT6165M83K Part Number 165uF High Voltage Film Capacitor Online
Discover the reliable and high-performance C44U-M high voltage film capacitor from KEMET. Designed for demanding power filtering, energy storage, and industrial applications, it offers excellent stability at 1500VDC. Its robust construction features screw terminals M6 for secure mounting, with dimensions of approximately 85mm in diameter and 124.5mm in length. Suitable for operating temperatures from -40°C to +85°C, this capacitor ensures dependable operation under challenging conditions, making it an essential component for power electronics and energy management systems.
Buy KEMET C44USGT6165M83K now and experience unmatched durability, high voltage stability, and excellent energy storage for power electronics.
Frequently Asked Questions
Where can I buy KEMET C44USGT6165M83K?
You can click on the BUY or RFQ button to purchase C44USGT6165M83K from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part C44USGT6165M83K?
You can download the C44USGT6165M83K datasheet or visit the KEMET website for support.
Who is the manufacturer of C44USGT6165M83K?
KEMET
