KEMET EE212SNUL Miniature Relay
The EE212SNUL is a compact, high-reliability miniature relay suitable for electronic switching, PBX, terminal equipment, and telephone systems. Featuring RoHS compliance, it offers various options such as high insulation and breakdown voltage types. The relay provides a maximum switching capacity of 125 VA with resistive loads, operate and release times around 2 ms and 1 ms respectively, and is designed for reliable operation across a temperature range of -40°C to +85°C. Its small footprint, high insulation standards, and diverse configurations make it ideal for space-constrained applications demanding durability and safety.
KEMET EE212SNUL Miniature Relay Specifications:
- Contact Material: Silver alloy with gold overlay
- Maximum Switching Capacity: 125 VA (resistive load)
- Operate Time: Approx. 2 ms
- Release Time: Approx. 1 ms
- Insulation Resistance: 1000 MΩ at 500 VDC
- Break Contact Voltage: 1000 VAC for 1 min, Surge: 1500 V
- Between open contacts: 4000 VAC for 1 min, Surge: 1500 V
- Between coil and contacts: 1500 VAC for 1 min, Surge: 2500 V
- Coil Resistance: 164.3Ω at 20°C for 3V, 579Ω for 9V, 2880Ω for 24V
- Coil Power: 140-200 mW depending on type
- Operating Temperature: -40°C to +85°C
- Weight: Approx. 1.9 g
- Vibration Resistance: 10-55 Hz, double amplitude 3-5 mm
- Shock Resistance: 980 m/s² (destructive), 735 m/s² (misoperation)
- Soldering Conditions: Reflow max 260°C for 5 sec, Manual max 350°C for 3 sec
- Packaging: Tube or embossed tape, reel diameter 380 mm
- RoHS compliant and UL, CSA recognized, TUV certified
Buy the NEC Series EC2 Switch: EE212SNUL
Enhance your electronic systems with the high-reliability NEC EE212SNUL miniature relay. Designed for space-constrained applications, it offers fast switching times, excellent insulation, and robust performance across temperatures from -40°C to +85°C. Suitable for PBX, terminal equipment, and communication systems, this RoHS-compliant relay ensures safety and durability. Easy to mount via tubes or tapes, it features a maximum switching capacity of 125 VA with resistive loads, making it ideal for various industrial applications requiring secure and efficient switching solutions.
Get NEC EE212SNUL relay today—built for high insulation and reliable electronic switching in miniaturized form.
Frequently Asked Questions
Where can I buy KEMET EE212SNUL?
You can click on the BUY or RFQ button to purchase EE212SNUL from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part EE212SNUL?
You can download the EE212SNUL datasheet or visit the KEMET website for support.
Who is the manufacturer of EE212SNUL?
KEMET
