KEMET ELH159M016AS1AA Aluminum Electrolytic Capacitor
The aluminum electrolytic capacitor designed for electronic applications features a 15,000 uF capacitance with a 20% tolerance, rated at 16 VDC with surge capability up to 20 VDC. Its dimensions include a diameter of 30mm and a length of 25mm, with a temperature range from -40°C to +85°C and a rated temperature of 85°C. It offers a lifespan of 2000 hours, dissipation factor of 55% at 120Hz, ripple current of 3500 mA at 120Hz, and leakage current of 3000 uA after 5 minutes at 20°C, suitable for power supplies and electronic circuits.
KEMET ELH159M016AS1AA Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 15,000 uF
- Capacitance Tolerance: 20%
- Voltage DC: 16 VDC (20 VDC surge)
- Dimensions: Diameter 30mm, Length 25mm
- Temperature Range: -40°C to +85°C
- Rated Temperature: 85°C
- Life Expectancy: 2000 hours
- Dissipation Factor: 55% at 120Hz, 20°C
- Ripple Current: 3500 mA at 120Hz
- Leakage Current: 3000 uA after 5 minutes at 20°C
- Packaging: Bulk, Bag
- Packaging Quantity: 200 units
Buy the Buy KEMET Aluminum Electrolytic Capacitor Part Number ELH159M016AS1AA Online
Purchase the high-capacity Aluminum Electrolytic Capacitor designed by KEMET online. With a 15,000 uF capacitance, 16 VDC rating, and robust temperature range from -40°C to +85°C, it is ideal for power supply filtering and electronic circuit stabilization. Its durable construction ensures a lifespan of 2000 hours, while the dissipation factor and ripple current specifications guarantee excellent performance under various operating conditions. Buy today for reliable performance and long-term stability in your electronic projects.
Get KEMET ELH159M016AS1AA today—built for high capacitance and long-lasting durability in electronic circuits.
Frequently Asked Questions
Where can I buy KEMET ELH159M016AS1AA?
You can click on the BUY or RFQ button to purchase ELH159M016AS1AA from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part ELH159M016AS1AA?
You can download the ELH159M016AS1AA datasheet or visit the KEMET website for support.
Who is the manufacturer of ELH159M016AS1AA?
KEMET
