KEMET ELH686M450AQ2AA Aluminum Electrolytic Capacitor
The aluminum electrolytic capacitor ELH686M450AQ2AA features a snap-in design with a capacitance of 68 uF and a voltage rating of 450 VDC. Suitable for industrial and power supply applications, it operates within a temperature range of -25°C to +85°C and has a life expectancy of 2000 hours. The capacitor's dimensions are D 22mm, L 30mm, with a lead spacing of 10mm. It offers a dissipation factor of 20% at 120Hz and a ripple current capacity of 700 mA, ensuring reliable operation in demanding environments.
KEMET ELH686M450AQ2AA Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 68 uF
- Capacitance Tolerance: 20%
- Voltage DC: 450 VDC, 500 VDC (Surge)
- Temperature Range: -25/+85°C
- Rated Temperature: 85°C
- Life: 2000 Hrs
- Dissipation Factor: 20% at 120Hz 20°C
- Resistance: 937 mOhms (20kHz 25°C)
- Ripple Current: 700 mA at 120Hz
- Leakage Current: 600 uA (5 min 20°C)
- Dimensions: Diameter 22mm (+1mm), Length 30mm (+2mm), Lead Spacing 10mm +/-0.5mm, Lead Length 5.8mm +/-1mm, Fillet 1.5mm +/-0.1mm
- Packaging: Bulk, Bag, Quantity: 400
Buy the KEMET ELH686M450AQ2AA – Reliable Aluminum Electrolytic Capacitor for Industrial Applications
Purchase the KEMET ELH686M450AQ2AA aluminum electrolytic capacitor online today to ensure reliable power stabilization in industrial equipment. With a high voltage rating of 450 VDC, durable snap-in design, and operating from -25°C to +85°C, this capacitor offers long-term performance for demanding applications. Its 68 uF capacitance, 20% tolerance, and 2000-hour lifespan make it ideal for power supplies, inverters, and motor control systems. Experience quick, secure ordering and fast delivery for your electronic component needs.
Order your KEMET Series ELH686M450AQ2AA high-voltage aluminum electrolytic capacitor today and enhance your industrial power supply projects with proven reliability.
Frequently Asked Questions
Where can I buy KEMET ELH686M450AQ2AA?
You can click on the BUY or RFQ button to purchase ELH686M450AQ2AA from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part ELH686M450AQ2AA?
You can download the ELH686M450AQ2AA datasheet or visit the KEMET website for support.
Who is the manufacturer of ELH686M450AQ2AA?
KEMET
