KEMET ESE227M025AG3AA Aluminum Electrolytic Capacitor
This aluminum electrolytic capacitor features a 220 uF capacitance with a voltage rating of 25 VDC, designed for reliable performance in varying temperature conditions from -40°C to +105°C. It has a lifespan of 1000 hours, a lead spacing of 3.5mm, and a ripple current capacity of 200 mA at 120Hz and 105°C. Suitable for applications requiring high capacity and stability, it complies with RoHS standards and offers a compact, durable design for industrial and electronic circuit needs.
KEMET ESE227M025AG3AA Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 220 uF
- Capacitance Tolerance: 20%
- Voltage DC: 25 VDC, 32 VDC (Surge)
- Temperature Range: -40°C to +105°C
- Lead Spacing: 3.5mm +/-0.5mm
- Dimensions: Diameter 8mm +/-0.5mm, Length 20mm +1-5mm
- Rated Temperature: 105°C
- Life: 1000 Hours
- Dissipation Factor: 16% at 120Hz 20°C
- Leakage Current: 55 uA at 20°C (2 min)
- Impedance Ratio: 3 at -25°C, 4 at -40°C
- Packaging: Bulk, Bag, Quantity: 6000
- RoHS Compliant: Yes
- Dielectric: Aluminum Electrolytic
- Series: ESE
- Construction: Single Ended, Aluminum
- Terminal: Wire Leads
Buy the KEMET ESE227M025AG3AA – Reliable Aluminum Electrolytic Capacitor for Industrial Applications
Buy KEMET aluminum electrolytic capacitor ESE227M025AG3AA today for your power supply and industrial applications. This high-capacity capacitor offers 220 uF at 25 VDC with a wide temperature range from -40°C to +105°C. Its compact size with 8mm diameter and 20mm length, coupled with a lead spacing of 3.5mm, makes it ideal for reliable, high-performance electronic circuits. RoHS compliant and designed to provide long-term stability, it ensures your projects maintain peak efficiency and durability while supporting demanding operational environments.
Get KEMET ESE227M025AG3AA today—built for precision, long-lasting durability, and reliable performance in industrial circuits.
Frequently Asked Questions
Where can I buy KEMET ESE227M025AG3AA?
You can click on the BUY or RFQ button to purchase ESE227M025AG3AA from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part ESE227M025AG3AA?
You can download the ESE227M025AG3AA datasheet or visit the KEMET website for support.
Who is the manufacturer of ESE227M025AG3AA?
KEMET
