KEMET ESK688M035AQ4AA Aluminum Electrolytic Capacitor
The ESK series aluminum electrolytic capacitor offers 6,800 microfarads with a 20% tolerance, rated for 35VDC, and operational from -40°C to +85°C. Designed with wire leads, it features a compact size with a 22mm diameter and 40mm length, ensuring reliable performance in various electronic applications. Suitable for power supplies, filtering, and energy storage, this capacitor provides a dissipation factor of 12% at 120Hz and 20°C, and can handle ripple currents up to 2600 mA. Its robust construction guarantees a lifespan of 2000 hours, making it ideal for demanding industrial environments.
KEMET ESK688M035AQ4AA Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 6,800 uF
- Capacitance Tolerance: 20%
- Voltage DC: 35 VDC, 44 VDC (Surge)
- Temperature Range: -40/+85°C
- Rated Temperature: 85°C
- Life: 2000 Hrs
- Dissipation Factor: 12% at 120Hz 20°C
- Ripple Current: 2600 mA at 120Hz 85°C
- Leakage Current: 2380 uA (2 min, 20°C)
- Impedance Ratio: 3 at -25°C and -40°C
- Dimensions: Diameter 22mm +/-0.5mm, Length 40mm +2mm, Lead Spacing 10mm +/-0.5mm, LL Negative 15mm MIN, LL Positive 20mm MIN, F 0.8mm NOM
- Packaging: Bulk, Bag, Quantity: 300
Buy the KEMET ESK688M035AQ4AA – Reliable Aluminum Electrolytic Capacitor for Industrial Applications
Purchase the KEMET ESK688M035AQ4AA aluminum electrolytic capacitor online today. Designed with a capacitance of 6800uF, 35VDC rating, and operating from -40°C to +85°C, it ensures outstanding performance in power supply filtering and energy storage applications. Its compact size of 22mm diameter and 40mm length makes it suitable for space-constrained designs, while the 2000-hour lifespan guarantees long-term reliability. Simplify your procurement process and ensure your project’s success by ordering online now—quality, performance, and durability at your fingertips.
Get KEMET ESK688M035AQ4AA today—built for performance, durability, and reliable power filtering in demanding industrial environments.
Frequently Asked Questions
Where can I buy KEMET ESK688M035AQ4AA?
You can click on the BUY or RFQ button to purchase ESK688M035AQ4AA from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part ESK688M035AQ4AA?
You can download the ESK688M035AQ4AA datasheet or visit the KEMET website for support.
Who is the manufacturer of ESK688M035AQ4AA?
KEMET
