KEMET LDECC2220JA5N00 Automotive Grade Film Capacitor
The LDE series capacitor by KEMET is a metallized PEN stacked film component designed for automotive applications, offering high reliability and stability. With a capacitance of 0.022 uF and a tolerance of 5%, it supports 40 VAC and 50 VDC ratings, with a maximum operating temperature of 125°C. Its compact 1812 chip size measures approximately 4.7mm in length, 3.3mm in width, and 1.7mm in height. Featuring RoHS compliance, an AEC-Q200 qualification, and a dissipation factor of 0.8% at 1 kHz, this SMD component provides excellent insulation resistance and durability for demanding environments.
KEMET LDECC2220JA5N00 Automotive Grade Film Capacitor Specifications:
- Capacitance: 0.022 uF
- Capacitance Tolerance: 5%
- Voltage AC: 40 VAC
- Voltage DC: 50 VDC
- Temperature Range: -55/+125°C
- Rated Temperature: 125°C
- Dielectric: Metallized PEN Stacked
- Style: SMD Chip
- Chip Size: 1812
- Dimensions: Length 4.7mm +0.3/-0.2mm, Width 3.3mm +/-0.3mm, Max Height 1.7mm
- Packaging: T&R, Quantity: 4000
- RoHS: Yes
- Qualifications: AEC-Q200
- Dissipation Factor: 0.8% at 1kHz
- Insulation Resistance: 1 GOhm
- Max dV/dt: 100 V/us
Buy the KEMET LDECC2220JA5N00 – Reliable Automotive Grade Capacitor for Industrial Applications
Experience the superior quality and durability of the KEMET LDE series automotive film capacitor, offering 0.022 uF capacitance, high temperature tolerance, and RoHS compliance. Ideal for industrial and automotive applications, this SMD chip provides excellent insulation resistance, stability, and resistance to environmental stress. Its compact 1812 size ensures easy integration into demanding systems. With a rated temperature of 125°C and qualification for AEC-Q200 standards, it guarantees long-term performance and reliability in critical environments. Purchase online today for dependable circuit protection and filtering.
Buy KEMET LDECC2220JA5N00 now and experience unmatched reliability and performance in demanding automotive and industrial circuits.
Frequently Asked Questions
Where can I buy KEMET LDECC2220JA5N00?
You can click on the BUY or RFQ button to purchase LDECC2220JA5N00 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part LDECC2220JA5N00?
You can download the LDECC2220JA5N00 datasheet or visit the KEMET website for support.
Who is the manufacturer of LDECC2220JA5N00?
KEMET
