KEMET LDEPD1220KA5N00 Automotive Grade SMD Capacitor
The LDEPD1220KA5N00 is a high-quality automotive-grade SMD chip capacitor with metallized PEN stacked dielectric, rated at 2200 pF with a 10% tolerance. Designed for demanding electronic applications, it offers a capacitance of 2200 pF, withstands voltages up to 200 VAC and 630 VDC, and operates within a temperature range of -55°C to +125°C. Its compact 2220 chip size ensures compatibility with surface-mount assemblies, making it suitable for automotive and industrial electronics requiring reliable performance and stability under harsh conditions.
KEMET LDEPD1220KA5N00 Automotive Grade SMD Capacitor Specifications:
- Capacitance: 2200 pF
- Capacitance Tolerance: 10%
- Voltage AC: 200 VAC
- Voltage DC: 630 VDC
- Temperature Range: -55°C to +125°C
- Rated Temperature: 125°C
- Dissipation Factor: 0.8% at 1kHz
- Insulation Resistance: 1 GOhms
- Max dVidt: 100 V/us
- Chip Size: 2220 (6mm x 5mm)
- Dimensions: Length 6mm ±0.3mm, Width 5mm ±0.4mm, Max Height 2mm
- Material: Metallized PEN
- Features: Automotive Grade, RoHS Compliant, AEC-Q200 Qualified
- Packaging: Tape & Reel, Quantity: 3000 units
- Component Weight: 0.267 g
- Shelf Life: 104 weeks
- MSL: 2a
Buy the KEMET Series LDE Capacitor: 2200 pF Automotive Grade Metallized PEN - LDEPD1220KA5N00
Purchase the KEMET LDEPD1220KA5N00 now for your high-reliability automotive and industrial applications. This 2200 pF metallized PEN stacked SMD capacitor offers excellent performance, stability, and durability under harsh conditions. With a rated voltage of 200 VAC and 630 VDC, it ensures safe and efficient operation across a wide temperature range from -55°C to +125°C. Ideal for compact designs, its RoHS compliance and AEC-Q200 qualification make it the perfect choice for demanding electronic systems requiring precision, robustness, and longevity.
Buy KEMET LDEPD1220KA5N00 now and experience unmatched reliability and performance for demanding automotive and industrial electronics.
Frequently Asked Questions
Where can I buy KEMET LDEPD1220KA5N00?
You can click on the BUY or RFQ button to purchase LDEPD1220KA5N00 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part LDEPD1220KA5N00?
You can download the LDEPD1220KA5N00 datasheet or visit the KEMET website for support.
Who is the manufacturer of LDEPD1220KA5N00?
KEMET
