KEMET MA2043 Noise Filter
The noise filter offers reliable noise suppression and EMI/RFI filtering for 250 VAC systems with a rated current of 4 A. Encased in a plastic box, it features a compact design with dimensions of 38mm length, 22.5mm height, and 7mm minimum width, making it suitable for various electronic applications. Its maximum leakage current is 0.75 mA at 250 V, and it can withstand voltage up to 1500 VAC. The product complies with RoHS, UL, CSA, and TUV standards, ensuring quality and safety in electrical noise filtering tasks.
KEMET MA2043 Noise Filter Specifications:
- Voltage AC: 250 VAC
- Withstanding Voltage: 1500 VAC
- Rated Current: 4 A (AC/DC)
- Dimensions: Length 38mm, Height 22.5mm, Width minimum 7mm
- Leakage Current: 0.75 mA MAX at 250 V, 60 Hz
- Insulation Resistance: 200 MOhms
- Temperature Range: -25°C to +55°C
- RoHS Compliant
- Certifications: UL, CSA, TUV
- Packaged in tray or box, quantity of 50 units
Buy the KEMET Series MA Noise Filter: MA2043
Enhance your electronic system’s noise suppression with the KEMET MA2043 noise filter, ideal for EMI/RFI filtering at 250 VAC with 4 A rated current. Encased in a durable plastic box, it features excellent insulation capabilities, a leakage current of only 0.75 mA, and withstands voltage up to 1500 VAC. RoHS compliant and certified by UL, CSA, and TUV, this compact filter ensures high performance, safety, and durability in various industrial and commercial applications. Order online today for reliable noise mitigation.
Get KEMET MA2043 noise filter today—designed for reliable noise suppression and high voltage insulation in electronic systems.
Frequently Asked Questions
Where can I buy KEMET MA2043?
You can click on the BUY or RFQ button to purchase MA2043 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part MA2043?
You can download the MA2043 datasheet or visit the KEMET website for support.
Who is the manufacturer of MA2043?
KEMET
