KEMET OHD335B Thermal Reed Switch
The KEMET OHD Thermal Reed Switch features radial tab leads, high-temperature accuracy at 35°C, and exceptional environmental durability. Designed for reliability, it offers high-speed response and long operational life, making it suitable for industrial and electronic applications. With UL, CSA, and TUV certifications, this switch operates within a temperature range of -20°C to +150°C, with a switching temperature of 35°C ±5°C. Its compact dimensions include a maximum length of 27mm, height of 6mm, and a contact resistance of 150 milliohms, supporting 0.3 Amps and voltage up to 110V AC/DC.
KEMET OHD335B Thermal Reed Switch Specifications:
- Switching Temperature: 35°C ±5°C
- Temperature Range: -20°C to +150°C
- Contact Type: Break
- Dimensions: Length 27mm max, Height 6mm, Width 13.5mm
- Voltage DC: 2500 VAC for 1 min, 3000 VAC for 1 sec
- Voltage AC: Max 110 VAC
- Current: Max 0.3 Amps AC/DC
- Contact Resistance: 150 mOhms max
- Max Power: 6 W (AC/DC)
- Max Voltage: 110 V (AC/DC)
- Differential Temperature: 10°C max
- Lead Type: Radial Tab
- RoHS & REACH compliant
- Certifications: UL, CSA, TUV
- Material: Thermal reed with high reliability and environmental durability
Buy the Buy KEMET Thermal Reed Switch Part Number OHD335B Online
Purchase the KEMET Thermal Reed Switch online today to ensure high reliability, excellent environmental durability, and precise temperature control for your industrial and electronic projects. Designed with radial tab leads, it features a switching temperature of 35°C, wide operating range from -20°C to +150°C, and UL, CSA, TUV certifications for safety and quality assurance. With a compact size, low contact resistance, and high power capacity, this switch is perfect for demanding applications requiring fast response and long operational life. Shop now for fast delivery and proven performance.
Buy KEMET OHD335B now and experience unmatched reliability and high-speed response in demanding electronic environments.
Frequently Asked Questions
Where can I buy KEMET OHD335B?
You can click on the BUY or RFQ button to purchase OHD335B from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part OHD335B?
You can download the OHD335B datasheet or visit the KEMET website for support.
Who is the manufacturer of OHD335B?
KEMET
