KEMET OHD395B Thermal Reed Switch
The KEMET OHD Thermal Reed Switch features radial tab mounting, high-temperature accuracy of 95°C with a ±5°C tolerance, and excellent environmental durability. It offers high reliability, fast response, and a long operational life. Designed for precise temperature switching from -20°C to +150°C, it has a contact type that breaks at 95°C, with a maximum voltage of 110 V AC/DC and a maximum current of 0.3 Amps. Suitable for applications requiring stable thermal control and environmental resilience, this switch ensures consistent performance in demanding conditions.
KEMET OHD395B Thermal Reed Switch Specifications:
- Switching Temperature: 95°C +/-5°C
- Temperature Range: -20°C to +150°C
- Contact Type: Break
- Dimensions: Length 27mm MAX, Height 6mm, Thickness 135mm
- Voltage DC: 2500 VAC/1 min, 3000 VAC/1 sec
- Voltage AC: 110 VAC MAX (Opening/Closing)
- Max Current: 0.3 Amps AC/DC
- Contact Resistance: 150 mOhms MAX
- Power Rating: 6 W (AC/DC)
- Max Voltage: 110 V (AC/DC)
- Differential Temperature: 10°C MAX
- Lead Type: Radial Tab Leads
- Weight: 24g
- Certifications: UL, CSA, TUV
- RoHS and REACH Compliant
Buy the KEMET OHD3-95B – Reliable Thermal Switch for Industrial Applications
Order the KEMET Thermal Reed Switch OHD3-95B online today to ensure precise temperature control in your industrial or electronic applications. This high-reliability switch features radial tab leads, a 95°C switching temperature, broad operating temperature range, and certified safety standards. Perfect for thermal management systems requiring environmental durability, fast response, and stable operation. With easy online purchasing, get consistent performance, quick delivery, and expert support to meet your project needs. Elevate your thermal control solutions now.
Buy KEMET OHD3-95B now and experience unmatched reliability and performance in thermal switching solutions.
