KEMET PEH200MJ5220MB2 Aluminum Electrolytic Capacitor
The PEH200MJ5220MB2 is a high-capacity aluminum electrolytic capacitor with a capacitance of 22,000 uF and a voltage rating of 63 VDC. Designed for reliable power smoothing and energy storage in electronic circuits, it features a screw terminal mounting, a -40°C to +85°C temperature range, and RoHS compliance. With a long shelf life of 156 weeks and a rated lifespan of 12,000 hours at rated voltage, this component is suitable for demanding industrial and power applications where high capacitance and durability are essential.
KEMET PEH200MJ5220MB2 Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 22,000 uF
- Capacitance Tolerance: 20%
- Rated Voltage DC: 63 VDC
- Temperature Range: -40°C to +85°C
- Dimensions: Diameter 51.6mm, Length 95.5mm
- Shelf Life: 156 weeks
- Lifespan: 12,000 hours at rated conditions
- Ripple Current: 42 Amps at 85°C (100Hz), 30.9 Amps at 10kHz
- Leakage Current: 8158 uA at 20°C
- Dissipation Factor: 8 mOhms at 100kHz, 20°C
- Weight: 240g
- Mounting: Stud, Insulated Cup
- RoHS Compliant: Yes
- Halogen Free: Yes
Buy the Buy KEMET Aluminum Electrolytic Capacitor Part Number PEH200MJ5220MB2 Online
Purchase the KEMET aluminum electrolytic capacitor with part number PEH200MJ5220MB2 online now. This high-capacitance component delivers 22,000 uF at 63 VDC, ideal for power smoothing, energy storage, and industrial applications. Its robust construction features screw terminal mounting, a wide temperature range from -40°C to +85°C, and a long shelf life of 156 weeks. Ensure the longevity and performance of your electronics with this durable, RoHS-compliant capacitor, ready for immediate shipping and use in demanding environments.
Order your KEMET series PEH200MJ5220MB2 aluminum electrolytic capacitor today and ensure your electronic projects benefit from high capacitance, durability, and reliable power storage.
Frequently Asked Questions
Where can I buy KEMET PEH200MJ5220MB2?
You can click on the BUY or RFQ button to purchase PEH200MJ5220MB2 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part PEH200MJ5220MB2?
You can download the PEH200MJ5220MB2 datasheet or visit the KEMET website for support.
Who is the manufacturer of PEH200MJ5220MB2?
KEMET
