KEMET PEH200MJ5220MU2 Aluminum Electrolytic Capacitor
The PEH200MJ5220MU2 is a high-capacity aluminum electrolytic capacitor with a capacitance of 22,000 uF, rated at 63 VDC and a temperature range of -40°C to +85°C. It features screw terminal design, suitable for industrial and power supply applications. With a lifespan of approximately 12,000 hours at rated voltage and ripple current capabilities of up to 42 Amps at 85°C, it is halogen free and RoHS compliant. Its compact dimensions include a diameter of 5.6mm and length of 95.5mm, making it versatile for demanding engineering environments.
KEMET PEH200MJ5220MU2 Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 22,000 uF
- Voltage DC: 63 VDC
- Temperature Range: -40°C to +85°C
- Dimensions: Diameter 5.6mm, Length 95.5mm
- Rated Temperature: 85°C
- Life: 12000 hours at rated voltage and ripple current
- Ripple Current: Up to 42 Amps at 85°C
- Leakage Current: 8158 μA at 20°C (5 minutes)
- Inductance: 16 nH (ESL)
- RoHS Certified: Yes
- Halogen Free: Yes
- Insulation: Screw terminal design
- Shelf Life: 156 weeks
- Packaging: Bulk, Bag, 20 units per pack
Buy the KEMET PEH200MJ5220MU2 – Reliable Aluminum Capacitor for Industrial Applications
Secure your industrial power solutions with the KEMET PEH200MJ5220MU2 aluminum electrolytic capacitor. Featuring a capacity of 22,000 uF and a voltage rating of 63 VDC, it offers exceptional performance across -40°C to +85°C. Designed with screw terminals, it provides easy installation and high durability. With a lifespan of 12,000 hours and ripple current capacity up to 42 Amps at 85°C, this halogen-free component is ideal for power supplies, industrial equipment, and demanding electrical systems. Purchase online today for reliable operation and long-term stability.
Buy KEMET PEH200MJ5220MU2 now and experience unmatched reliability and performance in demanding power and industrial circuits.
Frequently Asked Questions
Where can I buy KEMET PEH200MJ5220MU2?
You can click on the BUY or RFQ button to purchase PEH200MJ5220MU2 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part PEH200MJ5220MU2?
You can download the PEH200MJ5220MU2 datasheet or visit the KEMET website for support.
Who is the manufacturer of PEH200MJ5220MU2?
KEMET
