KEMET PEH200PJ5100MU2 Aluminum Electrolytic Capacitor
The PEH200PJ5100MU2 is a high-capacity aluminum electrolytic capacitor with a capacitance of 10,000 uF and a voltage rating of 100 VDC. Designed for robust power filtering and energy storage applications, it features a screw terminal for secure connectivity and a temperature range of -40°C to +85°C. Its compact dimensions include a diameter of 5.6mm and a length of 95.5mm, along with a low ESR of 19 mOhms at 20°C. The capacitor offers a long rated life of 12,000 hours and excellent ripple current capacity, making it ideal for industrial and electronics use.
KEMET PEH200PJ5100MU2 Aluminum Electrolytic Capacitor Specifications:
- Capacitance: 10,000 uF
- Capacitance Tolerance: 20%
- Voltage DC: 100 VDC
- Temperature Range: -40°C to +85°C
- Dimensions: Diameter 5.6mm, Length 95.5mm
- Rated Temperature: 85°C
- Life Expectancy: 12,000 hours
- Ripple Current: 15.3A (100Hz), 25.6A (10kHz)
- Leakage Current: 7000 uA (5 min at 20°C)
- ESL: 16 nH
- Resistance: 23 mOhms (100Hz 20°C), 19 mOhms (LOOKHz 20°C)
Buy the KEMET Series PEH200 Aluminum Electrolytic Capacitor: PEH200PJ5100MU2
Purchase the KEMET PEH200PJ5100MU2 aluminum electrolytic capacitor online today for your power filtering and energy storage needs. Designed for high performance, this capacitor features a 10,000 uF capacitance, 100 VDC voltage rating, and a compact size with a screw terminal for secure connections. Its operating temperature extends from -40°C to +85°C, ensuring durability in demanding environments. With a long 12,000-hour rated life, low ESR, and excellent ripple current capacity, it is ideal for industrial electronics, power supplies, and energy storage systems. Buy now to ensure reliable, long-lasting performance in your projects.
Get KEMET PEH200PJ5100MU2 today—built for durability and reliability in industrial power applications.
Frequently Asked Questions
Where can I buy KEMET PEH200PJ5100MU2?
You can click on the BUY or RFQ button to purchase PEH200PJ5100MU2 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part PEH200PJ5100MU2?
You can download the PEH200PJ5100MU2 datasheet or visit the KEMET website for support.
Who is the manufacturer of PEH200PJ5100MU2?
KEMET
