KEMET PFR5151J1000J11L4BULK Film Capacitor
The PFR5151J1000J11L4BULK is a film, foil polypropylene capacitor designed for general purpose applications. It features a 150 pF capacitance with a 5% tolerance, rated for 1000 VDC, and operates up to +105°C under certain conditions. The component has wire leads, radial style, and pulse capability. With RoHS compliance and a compact size of approximately 7.2mm length and 6mm height, this capacitor is suitable for diverse circuit requirements requiring high voltage and stability.
KEMET PFR5151J1000J11L4BULK Film Capacitor Specifications:
- Capacitance: 150 pF
- Capacitance Tolerance: 5%
- Voltage DC: 1000 VDC
- Voltage AC: 250 VAC
- Temperature Range: -55°C to +100°C, rated up to 85°C
- Insulation Resistance: 100 GOhms
- Dissipation Factor: 0.04% at 1kHz, 0.05% at 100kHz
- Dimensions: Length 7.2mm -0.5mm, Height 6mm -0.5mm, Width 4mm +1mm
- Lead Spacing: 5mm
- Material: Film/Foil Polypropylene
- Features: Pulse, RoHS compliant
- Style: Radial, wire leads
- Rated Temperature: 85°C
- Inductance: 6nH
Buy the KEMET Series PFR/F411 Film Capacitor: PFR5151J1000J11L4BULK
Order the KEMET PFR5151J1000J11L4BULK online today to ensure your circuits stay reliable with high-voltage polypropylene capacitors. This capacitor offers 150 pF capacitance with a 5% tolerance, rated for 1000 VDC, and operates up to +105°C, making it ideal for industrial and electronic applications. Its compact radial design with wire leads makes it easy to install, while RoHS compliance guarantees environmental safety. Trust our online store for quick delivery and authentic KEMET quality.
Buy KEMET PFR5151J1000J11L4BULK now and experience unmatched reliability and performance in high-voltage film capacitor applications.
