KEMET PFR5471J1000J12L4BULK Polypropylene Film Capacitor
The PFR5471J1000J12L4BULK is a high-quality film/foil polypropylene capacitor designed for general purpose applications. With a capacitance of 470 pF and a voltage rating of 1000 VDC, it operates efficiently at temperatures up to 85°C. Featuring wire leads and radial style, this component offers excellent dielectric properties, low dissipation factor of 0.04% at 1kHz, and RoHS compliance. Its compact dimensions (7.2mm length, 7mm height, 5.5mm width) make it suitable for space-constrained electronic circuits requiring reliable performance and high insulation resistance.
KEMET PFR5471J1000J12L4BULK Polypropylene Film Capacitor Specifications:
- Capacitance: 470 pF
- Capacitance Tolerance: 5%
- Voltage DC: 1000 VDC
- Voltage AC: 250 VAC
- Operating Temperature Range: -55/+100°C
- Rated Temperature: 85°C
- Dimensions: Length 7.2mm -0.5mm, Height 7mm -0.5mm, Width 5.5mm -0.5mm
- Lead Spacing: 5mm
- Insulation Resistance: 100 GOhms
- Dissipation Factor: 0.04% at 1kHz
- Material: Film/Foil Polypropylene
- Weight: 0.566 g
- RoHS Compliant
- Packaging: Bulk, Bag, Max voltage 1000 V
- Inductance: 6nH
Buy the KEMET Series PFR F411 Capacitor: PFR5471J1000J12L4BULK
Order the KEMET PFR5471J1000J12L4BULK capacitor online today to ensure reliable performance in your electronic circuits. Designed with high-quality film/foil polypropylene dielectric, this capacitor provides accurate 470 pF capacitance and withstands voltages up to 1000 VDC, making it ideal for general purpose applications. Its compact size and wire lead configuration simplify installation, while RoHS compliance guarantees environmentally safe manufacturing. Trust this durable component for high insulation resistance, low dissipation factor, and performance stability in demanding electronic systems. Buy now for fast delivery!
Get KEMET PFR5471J1000J12L4BULK today—built for precision and long-lasting durability in your electronic projects.
Frequently Asked Questions
Where can I buy KEMET PFR5471J1000J12L4BULK?
You can click on the BUY or RFQ button to purchase PFR5471J1000J12L4BULK from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part PFR5471J1000J12L4BULK?
You can download the PFR5471J1000J12L4BULK datasheet or visit the KEMET website for support.
Who is the manufacturer of PFR5471J1000J12L4BULK?
KEMET
