KEMET PHA225MLL3380QE4 Hybrid Capacitor
The PHA225MLL3380QE4 is a hybrid polymer axial capacitor with a capacitance of 380 µF and a voltage rating of 63 VDC. It features a temperature range of -40°C to +125°C, making it suitable for high-temperature and demanding industrial environments. With a RoHS compliant, halogen-free design, this capacitor offers reliable ripple current handling up to 25.3 Amps at 105°C and low ESR of 147 mOhms at 100Hz. Designed for robustness, it includes lead wires and is qualified for automotive and industrial applications, ensuring long-term durability and performance.
KEMET PHA225MLL3380QE4 Hybrid Capacitor Specifications:
- Capacitance: 380 µF
- Voltage Rating: 63 VDC
- Temperature Range: -40°C to +125°C
- Tolerance: -10%/+30%
- Form Factor: Axial
- Lead Wire: Yes
- RoHS Compliant: Yes
- Halogen Free: Yes
- Ripple Current: 25.3 Amps at 100kHz 105°C
- Leakage Current: 119.7 µA at 20°C
- ESR: 147 mOhms at 100Hz
- Dimensions: Length 182mm ±0.5mm, Lead Length 267mm ±1mm
- Qualification: AEC-Q200
- Weight: Not specified
- Packaging: Tray
Buy the YAGEO PHA225 U–2013 Reliable Hybrid Polymer Capacitors for Industrial Applications
Secure your YAGEO PHA225 Series Capacitor online today for dependable power stabilization in demanding industrial environments. With a capacitance of 380 microfarads and a voltage rating of 63 volts, it is engineered to operate reliably from -40°C to +125°C, making it ideal for high-temperature settings. Its robust construction includes lead wires and RoHS compliance, delivering excellent ripple current handling of up to 25.3 Amps at 105°C. Purchase now for fast delivery and superior performance assurance.
Order your YAGEO Series PHA225 axial capacitor today and ensure the reliable power performance your industrial and automotive projects demand.
Frequently Asked Questions
Where can I buy KEMET PHA225MLL3380QE4?
You can click on the BUY or RFQ button to purchase PHA225MLL3380QE4 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part PHA225MLL3380QE4?
You can download the PHA225MLL3380QE4 datasheet or visit the KEMET website for support.
Who is the manufacturer of PHA225MLL3380QE4?
KEMET
