KEMET PHE426DJ5390JR05 Film Capacitor
The PHE426/F 426 series metallized polypropylene film capacitor is designed for general-purpose applications. With a capacitance of 0.039 UF, it features a voltage rating of 100 VDC and a temperature range of -55°C to +105°C. The capacitor has a 5mm lead spacing, radial style, and pulse capabilities. Its dielectric material ensures high insulation resistance of 100 GOhms and low dissipation factor of 0.05% at 1kHz. Ideal for electronic circuits requiring reliable performance in industrial and consumer electronics, it offers RoHS compliance and is packaged in bulk for easy installation.
KEMET PHE426DJ5390JR05 Film Capacitor Specifications:
- Capacitance: 0.039 UF
- Capacitance Tolerance: 5%
- Voltage DC: 100 VDC
- Voltage AC: 63 VAC
- Temperature Range: -55°C to +105°C
- Lead Spacing: 5mm
- Dimensions: Max Length 7.2mm, Max Diameter 3.5mm
- Insulation Resistance: 100 GOhms
- Dissipation Factor: 0.05% at 1kHz
- Inductance: 6nH
- RoHS Compliant: Yes
- Packaging: Bulk, Bag, Quantity: 2000
Buy the KEMET Series PHE426 Film Capacitor: PHE426DJ5390JR05
Secure your electronic applications with the KEMET PHE426DJ5390JR05 film capacitor. Featuring 0.039 UF capacitance, 100 VDC voltage rating, and a temperature range of -55°C to +105°C, it ensures stable performance and high insulation resistance. The radial design with 5mm lead spacing makes installation straightforward. Ideal for industrial, consumer electronics, and pulse applications. Purchase online today to get reliable, RoHS-compliant components quickly and efficiently, ensuring your designs meet quality standards with ease.
Buy KEMET PHE426DJ5390JR05 now and experience unmatched reliability and high performance in your electronic projects.
Frequently Asked Questions
Where can I buy KEMET PHE426DJ5390JR05?
You can click on the BUY or RFQ button to purchase PHE426DJ5390JR05 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part PHE426DJ5390JR05?
You can download the PHE426DJ5390JR05 datasheet or visit the KEMET website for support.
Who is the manufacturer of PHE426DJ5390JR05?
KEMET
