KEMET PHE426KA5220JR05 Polypropylene Film Capacitor
This high-quality film capacitor features metallized polypropylene dielectric with radial leads, rated at 0.022 uF and 400 VDC. It offers reliable performance in general-purpose applications, with a temperature range from -55°C to +105°C and a maximum rated temperature of 85°C. The capacitor has a low dissipation factor of 0.05% at 1 kHz, high insulation resistance of 100 GOhms, and maximum dV/dt of 300 V/us, making it suitable for pulse and power circuits with aluminum or plastic enclosures. Its compact size and bulk packaging facilitate easy installation.
KEMET PHE426KA5220JR05 Polypropylene Film Capacitor Specifications:
- Capacitance: 0.022 uF
- Capacitance Tolerance: 5%
- Voltage DC: 400 VDC (296 VDC at 105°C)
- Temperature Range: -55°C to +105°C
- Rated Temperature: 85°C
- Dissipation Factor: 0.05% at 1 kHz, 0.25% at 100 kHz
- Insulation Resistance: 100 GOhms
- Max dV/dt: 300 V/us
- Inductance: 6 nH
- Dimensions: Length 13mm max, Height 9mm max, Thickness 4mm max, Lead Spacing 10mm ±0.4mm, Lead Diameter F 0.6mm
Buy the KEMET PHE426KA5220J – Reliable Polypropylene Film Capacitor for Industrial Applications
Purchase the KEMET PHE426KA5220J polypropylene film capacitor today and experience exceptional performance with high insulation resistance and low dissipation factor. Perfect for industrial power applications, pulse circuits, and general-purpose use, this capacitor offers reliable operation over a wide temperature range from -55°C to +105°C. Its compact radial design with 0.022 uF capacitance, 400 VDC voltage rating, and bulk packaging ensures easy installation and inventory management. Invest now for durable, high-performance circuit protection and filtering.
Get KEMET PHE426KA5220J today—built for precision and long-lasting durability in power and pulse circuits.
Frequently Asked Questions
Where can I buy KEMET PHE426KA5220JR05?
You can click on the BUY or RFQ button to purchase PHE426KA5220JR05 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part PHE426KA5220JR05?
You can download the PHE426KA5220JR05 datasheet or visit the KEMET website for support.
Who is the manufacturer of PHE426KA5220JR05?
KEMET
