KEMET R413I14700000M Automotive Safety Capacitor
This automotive-grade metallized polypropylene capacitor features a capacitance of 4700 pF with a tolerance of 20%, rated for 300 VAC (Y2) and 1000 VDC operation. Designed for safety and EMI filtering, it complies with AEC-Q200 standards and is RoHS certified. The radial leaded component measures 18mm in length, 11mm in height, with a thickness of 5mm. It offers excellent insulation resistance of 100 GOhms, with a maximum voltage change rate of 600 V per microsecond, suitable for automotive and electronic safety applications.
KEMET R413I14700000M Automotive Safety Capacitor Specifications:
- Capacitance: 4700 pF
- Capacitance Tolerance: 20%
- Voltage AC: 300 VAC
- Voltage DC: 1000 VDC
- Temperature Range: -40/+110°C
- Rated Temperature: 110°C
- Dimensions: Length 18mm +0.3/-0.5mm, Height 11mm +0.1/-0.5mm, Thickness 5mm +0.2/-0.5mm
- Lead Spacing: 15mm
- Dissipation Factor: 0.2% 1KHz
- Insulation Resistance: 100 GOhms
- Maximum dV/dt: 600 V/us
Buy the Buy KEMET Automotive Safety Capacitor Part Number R413114700000M Online
Purchase the KEMET R413114700000M online to benefit from high-quality automotive safety capacitors designed for EMI filtering and reliable performance in demanding environments. With a capacitance of 4700 pF, 20% tolerance, rated for 300 VAC and 1000 VDC, this radial leaded component meets industry standards like AEC-Q200 and RoHS. Its robust insulation resistance of 100 GOhms and temperature range of -40°C to +110°C ensure durability and safety in automotive and electronic applications. Order now for fast, secure delivery and trusted quality.
Buy KEMET R413114700000M now and ensure reliable automotive safety and EMI filtering with high-voltage polypropylene capacitors.
Frequently Asked Questions
Where can I buy KEMET R413I14700000M?
You can click on the BUY or RFQ button to purchase R413I14700000M from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part R413I14700000M?
You can download the R413I14700000M datasheet or visit the KEMET website for support.
Who is the manufacturer of R413I14700000M?
KEMET
