KEMET T498B105K035ATE4K4 High-Temp Tantalum Capacitor
The T498B105K035ATE4K4 is a high-temperature Manganese Dioxide Tantalum SMD capacitor designed for automotive and industrial applications. It features a capacitance of 1uF with a 10% tolerance and a voltage rating of 35VDC at 85°C, suitable for use in rugged environments up to 150°C. The component measures approximately 3.5mm in length, 2.8mm in width, and 1.9mm in height, with a tin termination for reliable soldering. Its robust construction incorporates molded Hi-Temp design, ensuring stability and performance in demanding conditions, and it conforms to AEC-Q200 standards for automotive reliability.
KEMET T498B105K035ATE4K4 High-Temp Tantalum Capacitor Specifications:
- Capacitance: 1uF
- Capacitance Tolerance: 10%
- Voltage DC: 35 VDC at 85°C, 28 VDC at 125°C
- Temperature Range: -55°C to +150°C
- Dimensions: Length 3.5mm ±0.2mm, Width 2.8mm ±0.2mm, Height 1.9mm ±0.2mm
- Material: MnO2 Tantalum, Molded, Hi-Temp
- Termination: Tin
- Dissipation Factor: 3% at 120Hz 25°C
- Leakage Current: 0.5 µA (5 min, 25°C)
- Rated Temperature: 85°C
- Ripple Current: 125.1 mA rms at 85°C, 41.7 mA rms at 150°C
- Failure Rate: N/A, RoHS Compliant
- Shelf Life: 156 Weeks
- Packaging: T&R, 178mm, 2000 pcs
Buy the Buy KEMET T498B105K035ATE4K4 Part Number 7498 Online
Discover the reliable KEMET high-temperature tantalum capacitor designed for demanding applications. This 1uF, 35VDC SMD component with molded Hi-Temp construction offers exceptional stability from -55°C to +150°C. It features tin termination for secure soldering, RoHS compliance, and a compact footprint of approximately 3.5mm x 2.8mm x 1.9mm. Ideal for automotive, industrial, and rugged environments, this capacitor ensures durability and consistent performance, making it the perfect choice for your high-temperature electronic needs.
Order your KEMET Series7498 T498B105K035ATE4K4 high-temperature tantalum capacitor today and ensure reliable performance in automotive and industrial projects.
Frequently Asked Questions
Where can I buy KEMET T498B105K035ATE4K4?
You can click on the BUY or RFQ button to purchase T498B105K035ATE4K4 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part T498B105K035ATE4K4?
You can download the T498B105K035ATE4K4 datasheet or visit the KEMET website for support.
Who is the manufacturer of T498B105K035ATE4K4?
KEMET
