KEMET R413I222050M1M EMI Suppression Capacitor
The R41 Series EMI suppression capacitors are metallized polypropylene film components designed for electromagnetic interference filtering in across-the-line applications. Rated at 300 VAC and 110°C, these automotive-grade capacitors meet stringent safety and environmental standards, including UL, ENEC, cUL, and CQC approvals. They feature self-healing properties, high climatic category performance, and are optimized for reliability in automotive and industrial environments. With a broad capacitance range from 0.001 to 1 UF, various lead spacing options, and RoHS compliance, they are ideal for EMI suppression in sensitive electronic circuits.
KEMET R413I222050M1M EMI Suppression Capacitor Specifications:
- Dielectric: Polypropylene film
- Plates: Metal layer deposited by evaporation under vacuum
- Winding: Non-inductive type
- Leads: Tinned wire
- Protection: Plastic case, thermosetting resin filled, UL94 V-0 flame retardant
- Rated Voltage: 300 VAC (50/60 Hz), 1000 VDC
- Capacitance Range: 0.001 UF to 1 UF
- Capacitance Tolerance: +20%, +10%
- Operating Temperature: -40°C to +110°C
- Climatic Category: 40/110/56 IEC 60068-1
- Dissipation Factor: 0.3% (0.2% typical) @ 1kHz +25°C
- Insulation Resistance: ≥150,000 MΩ at 100 VDC
- Test Voltage: 5,000 VDC/2,500 VAC factory screening
- Approvals: UL, ENEC, cUL, CQC
- RoHS Compliant: Yes
- Lead Spacing: 7.5 to 37.5 mm (varies by model)
- Dimensions: Vary according to capacitance and lead spacing, typical sizes from 40mm to 75mm
Buy the KEMET Series R41 EMI Suppression: 300 VAC Automotive Grade Polypropylene Capacitor
Discover the high-performance KEMET R41 Series EMI suppression capacitors, rated at 300 VAC and 110°C. These automotive-grade polypropylene film components are excellent for electromagnetic interference filtering in across-the-line applications. They feature RoHS compliance, UL approvals, and self-healing properties for long-term reliability. Designed with broad capacitance options from 0.001 to 1 UF, various lead spacing sizes, and rugged construction, they ensure safe, effective EMI suppression in automotive and industrial electronics. Purchase online today for superior performance and compliance.
Buy KEMET R41 Capacitors now and experience unmatched reliability and performance in electromagnetic interference filtering applications.
Frequently Asked Questions
Where can I buy KEMET R413I222050M1M?
You can click on the BUY or RFQ button to purchase R413I222050M1M from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part R413I222050M1M?
You can download the R413I222050M1M datasheet or visit the KEMET website for support.
Who is the manufacturer of R413I222050M1M?
KEMET
