KEMET R463I233000H1K Film Capacitor
The R46 series film capacitor features a metallized polypropylene dielectric with a capacitance of 0.033 uF and a voltage rating of 310 VAC and 630 VDC. Designed for safety and EMI filtering, it operates reliably at temperatures up to 125°C. With a radial lead style and lead spacing of 15mm, it is RoHS compliant and suitable for various electronic applications. Its compact dimensions include an 18mm length and 40.1mm height, making it ideal for circuit protection, filtering, and safety applications demanding high voltage and stability.
KEMET R463I233000H1K Film Capacitor Specifications:
- Capacitance: 0.033 uF
- Capacitance Tolerance: 10%
- Voltage AC: 310 VAC
- Voltage DC: 630 VDC
- Dielectric: Metallized Polypropylene
- Temperature Range: -40°C to +125°C
- Rated Temperature: 125°C
- Dimensions: Length 18mm +0.3/-0.5mm, Height 40.1mm -0.5mm
- Lead Spacing: 15mm +/-0.4mm
- Dissipation Factor: 0.3% at 1kHz
- Insulation Resistance: 100 GOhms
- Maximum dVidt: 400 V/us
- Features: EMI Safety, RoHS compliant, Safety Class X2
- Packaging: Bulk, Bag
- Component Weight: 1.2g
Buy the Buy KEMET High-Voltage Film Capacitor Part Number R4631233000H1K Online
Order the KEMET film capacitor R4631233000H1K online today for dependable high-voltage filtering and safety features. This metallized polypropylene capacitor offers 0.033 uF capacitance, operates at 310 VAC and 630 VDC, and is designed for safety, EMI filtering, and reliability in industrial and electronic circuits. Its radial construction, compact size, and RoHS compliance make it suitable for demanding applications requiring high voltage stability and temperature endurance up to 125°C. Purchase now for fast delivery and superior quality assurance.
Buy KEMET R4631233000H1K now and experience unmatched reliability and safety in high-voltage filtering applications.
Frequently Asked Questions
Where can I buy KEMET R463I233000H1K?
You can click on the BUY or RFQ button to purchase R463I233000H1K from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part R463I233000H1K?
You can download the R463I233000H1K datasheet or visit the KEMET website for support.
Who is the manufacturer of R463I233000H1K?
KEMET
