KEMET R46KN415000P1M Filament Capacitor
The R46KN415000P1M is a mini, metallized polypropylene film capacitor designed for safety and EMI filtering applications. It features a capacitance of 1.5 uF with 20% tolerance, rated for 275 VAC (X2) and 560 VDC, operating efficiently at temperatures from -40°C to +110°C. This radial style component complies with safety standards including UL, ENEC, cUL, and CQC. Its compact design with lead spacing of 22.5mm makes it suitable for various industrial and electronic applications requiring high reliability and safety performance.
KEMET R46KN415000P1M Filament Capacitor Specifications:
- Capacitance: 1.5 uF
- Capacitance Tolerance: 20%
- Voltage AC: 275 VAC (X2)
- Voltage DC: 560 VDC
- Temperature Range: -40°C to +110°C
- Rated Temperature: 110°C
- Dielectric: Metallized Polypropylene
- Style: Radial
- Lead Spacing: 22.5mm +/-0.4mm
- Dimensions: Length 26.5mm +0.3/-0.5mm, Height 18.5mm +0.1/-0.5mm, Thickness 10mm +0.2/-0.5mm, Lead Length 4mm +2mm
- Dissipation Factor: 0.1% at 1kHz
- Insulation Resistance: 20 GOhms
- Max dV/dt: 200 V/us
- Features: EMI Safety, Safety Class X2
- Qualifications: ENEC, UL, cUL, CQC
- RoHS Compliant: Yes
- Packaging: Bulk, Bag, Quantity: 396
Buy the KEMET Series R46 275 VAC MINI: R46KN415000P1M
Purchase your KEMET Series R46KN415000P1M filament capacitor online today to benefit from high safety standards, excellent EMI filtering, and reliable performance. This 1.5 uF, 275 VAC safety-rated capacitor offers outstanding insulation resistance of 20 GOhms, operates effectively between -40°C and +110°C, and is suitable for industrial and electronic applications requiring high reliability. With UL, ENEC, cUL, and CQC certifications, this radial style component with 22.5mm lead spacing is ideal for projects demanding safety and performance, providing peace of mind for your electronic systems.
Order your KEMET Series R46KN415000P1M capacitor today and ensure your safety and EMI filtering with this high-quality, reliable component.
Frequently Asked Questions
Where can I buy KEMET R46KN415000P1M?
You can click on the BUY or RFQ button to purchase R46KN415000P1M from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part R46KN415000P1M?
You can download the R46KN415000P1M datasheet or visit the KEMET website for support.
Who is the manufacturer of R46KN415000P1M?
KEMET
