KEMET R60PN3680AA40K Automotive Film Capacitor
The R60PN3680AA40K is a metallized polyester film capacitor designed for automotive applications, featuring a 0.68 uF capacitance, 10% tolerance, and a maximum voltage of 630 VDC. It operates efficiently within a temperature range of -55°C to +105°C, with an upper operating temperature of 125°C allowed for up to 1,000 hours. The capacitor has a radial H style with lead spacing of 22.5mm, dimensions of approximately 26.5mm length, 20mm height, and 11mm thickness. It ensures reliable insulation resistance of 10 GOhms and dissipation factor of 1% at 1kHz, suitable for demanding electrical environments.
KEMET R60PN3680AA40K Automotive Film Capacitor Specifications:
- Capacitance: 0.68 uF
- Capacitance Tolerance: 10%
- Voltage DC: 630 VDC
- Voltage AC: 220 VAC
- Temperature Range: -55°C to +105°C
- Rated Temperature: 85°C
- Operating Temperature: Up to 125°C for 1,000 hours
- Dimensions: Length 26.5mm +0.3mm, Height 20mm +0.1mm, Thickness 11mm +0.2mm, Lead Spacing 22.5mm +/-0.4mm
- Dissipation Factor: 1% at 1kHz
- Insulation Resistance: 10 GOhms
- Maximum dV/dt: 12 V/μs
- Inductance: 18 nH
- RoHS Compliant, AEC-Q200 qualified
- Features: Metallized polyester dielectric, radial H style, lead cut, bulk packaging
- Weight: 7.8g
Buy the Buy KEMET 0.68 uF Film Capacitor Part Number R60PN3680AA40K Online
Get the KEMET R60PN3680AA40K film capacitor online today for your automotive and industrial projects. Offering 0.68 uF capacitance, 630 VDC voltage rating, and RoHS compliance, this high-quality capacitor is suitable for demanding environments. It features a radial style with lead spacing of 22.5mm, operates within a temperature range from -55°C to +105°C, and maintains excellent insulation resistance. Perfect for reliable, long-lasting electronic systems, this capacitor ensures your project meets demanding electrical standards with ease.
Order your KEMET SeriesR60 0.68 uF automotive-grade capacitor today and ensure reliable performance in demanding electrical environments.
Frequently Asked Questions
Where can I buy KEMET R60PN3680AA40K?
You can click on the BUY or RFQ button to purchase R60PN3680AA40K from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part R60PN3680AA40K?
You can download the R60PN3680AA40K datasheet or visit the KEMET website for support.
Who is the manufacturer of R60PN3680AA40K?
KEMET
