KEMET R75GN415050H0J Automotive Film Capacitor
The R75G series capacitor by KEMET is a high-quality automotive-grade film capacitor with metallized polypropylene dielectric, designed for pulse applications. It features a capacitance of 15uF with a 5% tolerance, rated for 160 VDC operation and capable of withstanding temperatures from -55°C to +125°C. Its radial lead style with 22.5mm spacing ensures ease of installation. This capacitor’s robust construction and low dissipation factor of 0.06% at 1kHz make it ideal for automotive and power electronic applications, ensuring reliable performance in demanding environments.
KEMET R75GN415050H0J Automotive Film Capacitor Specifications:
- Capacitance: 15uF
- Capacitance Tolerance: 5%
- Rated Voltage DC: 160 VDC
- Voltage AC: 90 VAC
- Temperature Range: -55°C to +125°C
- Rated Temperature: 105°C
- Dimensions: Length 26.5mm +0.3/-0.5mm, Height 18.5mm +0.1/-0.5mm, Lead Spacing 22.5mm +/-0.4mm
- Dissipation Factor: 0.06% at 1kHz
- Insulation Resistance: 20 GOhms
- Resistance: 10.61 mOhms (100kHz)
- Ripple Current: Up to 90°C, 105mA
- Inductance: 16 nH
- RoHS Compliant: Yes
- Compliance: AEC-Q200 qualified
- Package: Bulk, Bag, Quantity: 300
Buy the Buy KEMET Automotive Capacitor Part Number R75GN415050H0J Online
Enhance your electronic projects with the KEMET Automotive Film Capacitor, R75GN415050H0J. This high-quality, metallized polypropylene capacitor offers 15uF capacitance, 160 VDC rating, and operates from -55°C to +125°C, making it ideal for automotive and pulse applications. Its radial form with 22.5mm lead spacing ensures easy installation. Designed for durability and high performance, it’s compliant with RoHS and AEC-Q200 standards. Purchase online today for reliable, ready-to-install power, ensuring your devices operate smoothly under demanding conditions.
Order your KEMET Series R75GN415050H0J high-performance film capacitor today and ensure your automotive or power electronics projects achieve reliable, high-quality performance.
Frequently Asked Questions
Where can I buy KEMET R75GN415050H0J?
You can click on the BUY or RFQ button to purchase R75GN415050H0J from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part R75GN415050H0J?
You can download the R75GN415050H0J datasheet or visit the KEMET website for support.
Who is the manufacturer of R75GN415050H0J?
KEMET
