KEMET R75PF212050H3J automotive film capacitor
The product is a high-quality metallized polypropylene film capacitor designed for automotive applications. It features a capacitance of 0.012 microfarads with a 5% tolerance, and a voltage rating of 630 VDC, capable of operating within a temperature range of -55°C to +125°C. Built with wire leads and RoHS compliance, it offers excellent pulse performance, low dissipation factor, and robust insulation resistance. Suitable for demanding automotive electronics, this capacitor ensures reliable operation under harsh conditions and meets AEC-Q200 qualifications for automotive standards.
KEMET R75PF212050H3J automotive film capacitor Specifications:
- Capacitance: 0.012 uF
- Capacitance Tolerance: 5%
- Voltage Rating: 630 VDC
- AC Voltage: 250 VAC
- Lead Spacing: 10 mm
- Dimensions: Length 13 mm +0.2/-0.5 mm
- Temperature Range: -55°C to +125°C
- Rated Temperature: 105°C
- Dissipation Factor: 0.04% at 1kHz
- Insulation Resistance: 100 GOhms
- Maximum Voltage Variation: 2000 V
- Resistance: 92.84 mOhms at 100 kHz
- Ripple Current Capacity: 24A at 90°C
- Inductance: 9 nH
- RoHS Compliant: Yes
- Qualification: AEC-Q200
- Features: Automotive Grade, Pulse Capability
Buy the KEMET Series R75H Metallized Polypropylene Capacitor: R75PF212050H3J
Purchase your KEMET Series R75H automotive-grade metallized polypropylene film capacitor today for high reliability in demanding environments. With a capacitance of 0.012 microfarads, a high voltage rating of 630 volts DC, and operation across -55°C to +125°C, this capacitor provides outstanding pulse and ripple performance. Featuring RoHS compliance, low dissipation factor, and AEC-Q200 qualification, it is ideal for automotive electronics that require durability and resistance to extreme conditions. Buy online now for fast delivery and technical support.
Order your KEMET Series R75H metallized polypropylene film capacitor today and ensure reliable automotive performance under harsh conditions.
Frequently Asked Questions
Where can I buy KEMET R75PF212050H3J?
You can click on the BUY or RFQ button to purchase R75PF212050H3J from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part R75PF212050H3J?
You can download the R75PF212050H3J datasheet or visit the KEMET website for support.
Who is the manufacturer of R75PF212050H3J?
KEMET
