KEMET R75TN312050H3J Automotive Film Capacitor
The R75H series is a high-voltage metallized polypropylene film capacitor designed for automotive and pulse applications. Featuring a capacitance of 0.12 uF with a 5% tolerance, it operates reliably at temperatures up to 105°C and withstands voltages up to 1600 VDC. Its radial lead configuration and robust construction make it suitable for demanding industrial environments. Compliant with RoHS standards and qualified under AEC-Q200, this capacitor ensures durability, stability, and efficiency for automotive-grade electronic circuits. Its compact size and high insulation resistance provide excellent performance in surge and pulse conditions.
KEMET R75TN312050H3J Automotive Film Capacitor Specifications:
- Dielectric: Metallized Polypropylene
- Capacitance: 0.12 uF
- Capacitance Tolerance: 5%
- Voltage DC: 1600 VDC
- Voltage AC: 650 VAC
- Operating Temperature Range: -55°C to +125°C
- Rated Temperature: 105°C
- Lead Spacing: 22.5mm ±0.4mm
- Dimensions: Length 26.5mm +0.3/-0.5mm, Height 18mm +0.2/0.6mm
- Insulation Resistance: 100 GOhms
- Dissipation Factor: 0.05% at 1kHz, 0.08% at 10kHz
- Ripple Current: up to 900mA
- Inductance: 16 nH
- RoHS Compliant: Yes
- Qualification: AEC-Q200
- Packaging: Bulk, Bag, Quantity 200
- Resistance: 26.5 mOhms (at 100kHz)
- Max dV/dt: 3000 V/μs
Buy the KEMET R75TN312050H3J – Reliable Automotive Film Capacitor for Industrial Applications
Purchase the KEMET automotive-grade film capacitor R75TN312050H3J online today. Designed for high-voltage, pulse, and industrial applications, it features 0.12uF capacitance at 1600VDC, with a temperature range from -55°C to +125°C. Its robust dielectric and radial lead configuration ensure durability and stability in demanding environments. Ideal for engineers seeking dependable, high-quality components for electronic systems requiring excellent insulation resistance, low inductance, and compliance with industry standards. Get yours now for long-lasting performance and peace of mind.
Get KEMET R75TN312050H3J today—built for automotive-grade reliability, high-voltage endurance, and pulse performance in industrial circuits.
Frequently Asked Questions
Where can I buy KEMET R75TN312050H3J?
You can click on the BUY or RFQ button to purchase R75TN312050H3J from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part R75TN312050H3J?
You can download the R75TN312050H3J datasheet or visit the KEMET website for support.
Who is the manufacturer of R75TN312050H3J?
KEMET
