KEMET R76PN31205050J Automotive Film Capacitor
The R76PN31205050J is a high-quality automotive-grade film capacitor featuring double metallized polypropylene dielectric, ideal for pulse applications. It has a capacitance of 0.12 microfarads with a tolerance of 5%, rated at 630 VDC and an operating temperature range of -55°C to +110°C. Suitable for demanding automotive and industrial environments, this radial lead component offers excellent insulation resistance of 100 GOhms and can handle ripple currents up to 4.8 Amps at 85°C. Its compact size and RoHS compliance make it a reliable choice for electronic projects requiring precise and durable capacitance.
KEMET R76PN31205050J Automotive Film Capacitor Specifications:
- Capacitance: 0.12 uF
- Capacitance Tolerance: 5%
- Rated Voltage DC: 630 VDC
- Voltage AC: 400 VAC
- Temperature Range: -55°C to +110°C
- Operating Temperature: 85°C
- Insulation Resistance: 100 GOhms
- Dissipation Factor: 0.03% at 1kHz, 0.06% at 10kHz
- Lead Spacing: 22.5mm ±0.4mm
- Dimensions: Length 26.5mm +0.3/-0.5mm, Height 15mm +0.1/-0.5mm, Thickness 6mm +0.2/-0.5mm
- Ripple Current: 4.8 Amps (Peak at 85°C, 100kHz)
- Inductance: 16 nH
- RoHS Compliant: Yes
- Features: Automotive Grade, Pulse Capability
- Mounting Type: Radial
- Construction: Double Metallized Polypropylene Dielectric
- Compliance: AEC-Q200 qualified
Buy the KEMET Series R76 Automotive Grade Film Capacitor: R76PN31205050J
Enhance your electronic designs with the KEMET R76PN31205050J automotive-grade film capacitor. Featuring double metallized polypropylene dielectric, 0.12 microfarad capacitance, 630 VDC rating, and operating across -55°C to +110°C, this capacitor ensures exceptional performance for pulse and automotive applications. Its radial lead design offers easy mounting, high insulation resistance, and reliable operation under demanding conditions. Perfect for engineers seeking durable, RoHS-compliant components that deliver high ripple current ratings. Order online today and ensure your project’s success with trusted quality.
Buy KEMET R76PN31205050J now and experience unmatched reliability and performance for automotive and industrial applications.
Frequently Asked Questions
Where can I buy KEMET R76PN31205050J?
You can click on the BUY or RFQ button to purchase R76PN31205050J from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part R76PN31205050J?
You can download the R76PN31205050J datasheet or visit the KEMET website for support.
Who is the manufacturer of R76PN31205050J?
KEMET
