KEMET R82DC3680AA60K Automotive Capacitor
The R82DC3680AA60K is a high-quality automotive grade metallized polyester stacked capacitor designed for demanding electronic applications. Featuring a capacitance of 0.68 microfarads with a tolerance of 10%, it operates at 63 VDC and can withstand temperatures from -55°C to +105°C. This radial style capacitor, with a lead spacing of 5mm, is RoHS compliant, AEC-Q200 qualified, and offers a dissipation factor of 0.8% at 1kHz. Its compact dimensions and robust dielectric make it ideal for vehicle electronic systems requiring reliable, long-lasting performance.
KEMET R82DC3680AA60K Automotive Capacitor Specifications:
- Capacitance: 0.68 uF
- Capacitance Tolerance: 10%
- Voltage DC: 63 VDC
- Voltage AC: 40 VAC
- Temperature Range: -55°C to +105°C
- Rated Temperature: 85°C
- Lead Spacing: 5mm
- Dimensions: Length 7.2mm +0.3mm, Height 9.5mm +0.1mm, Thickness 4.5mm +0.1mm
- Dissipation Factor: 0.8% at 1kHz
- Insulation Resistance: 7.3529 GOhms
- Max dV/dt: 160 V/us
- Inductance: 7nH
- Features: RoHS compliant, AEC-Q200 qualified
- Material: Metallized polyester dielectric
- Package Quantity: 1500 units
Buy the Buy KEMET Metallized Polyester Capacitor Part Number R82DC3680AA60K Online
Acquire the KEMET R82DC3680AA60K, an automotive grade metallized polyester capacitor designed for high reliability and durability. With a capacitance of 0.68 microfarads, a maximum voltage of 63 VDC, and operating temperature from -55°C to +105°C, it offers excellent stability. Its radial design with 5mm lead spacing makes installation straightforward. Perfect for vehicle electronic systems, this capacitor ensures long-term performance, RoHS compliance, and qualification to industry standards, making it an essential component for automotive and industrial applications.
Get KEMET R82DC3680AA60K today—built for automotive reliability and long-lasting performance in demanding environments.
Frequently Asked Questions
Where can I buy KEMET R82DC3680AA60K?
You can click on the BUY or RFQ button to purchase R82DC3680AA60K from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part R82DC3680AA60K?
You can download the R82DC3680AA60K datasheet or visit the KEMET website for support.
Who is the manufacturer of R82DC3680AA60K?
KEMET
