KEMET R82MC1220AA50K Metallized Polyester Capacitor
The R82 series metallized polyester stacked film capacitor offers reliable performance with a capacitance of 2200 pF and a 10% tolerance, suitable for automotive applications. Designed with RoHS compliance and AEC-Q200 qualification, it features a voltage rating of 400 VDC and a maximum operating temperature of 85°C. Its radial style with a lead spacing of 5mm ensures easy mounting. The capacitor's dimensions include a length of 7.2mm, height of 6.5mm, and thickness of 2.5mm, making it ideal for demanding electronic circuits requiring stability and durability.
KEMET R82MC1220AA50K Metallized Polyester Capacitor Specifications:
- Capacitance: 2200 pF
- Capacitance Tolerance: 10%
- Voltage DC: 400 VDC
- Voltage AC: 200 VAC
- Temperature Range: -55°C to +105°C
- Rated Temperature: 85°C
- Dimensions: Length 7.2mm +0.2mm, Height 6.5mm +0.1mm, Thickness 2.5mm +0.1mm
- Lead Spacing: 5mm +/-0.4mm
- Material: Metallized Polyester Stacked
- RoHS Compliant: Yes
- Qualification: AEC-Q200
- Dissipation Factor: 0.02%
- Insulation Resistance: 30 GOhms
- Max dV/dt: 400 V/μs
- Inductance: 7nH
Buy the KEMET Series R82 Capacitor: 2200 pF Metallized Polyester Stack 400 VDC
Discover the high-reliability KEMET Series R82 metallized polyester capacitor with 2200 pF capacitance, 400 VDC voltage rating, and automotive-grade durability. Designed for demanding electronic applications, it features RoHS compliance, AEC-Q200 qualification, and a compact radial design with lead spacing of 5mm. Its robust construction excels in high-temperature environments up to 85°C, offering excellent insulation resistance of 30 GOhms and low dissipation factor. Perfect for circuit stability, filtering, and energy storage, this capacitor is an essential component for advanced electronic systems.
Order your KEMET Series R82 2200 pF metallized polyester film capacitor today and ensure your automotive and electronic projects have reliable, high-quality components.
Frequently Asked Questions
Where can I buy KEMET R82MC1220AA50K?
You can click on the BUY or RFQ button to purchase R82MC1220AA50K from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part R82MC1220AA50K?
You can download the R82MC1220AA50K datasheet or visit the KEMET website for support.
Who is the manufacturer of R82MC1220AA50K?
KEMET
