KEMET T494A106M020AT Tantalum Capacitor
The T494A106M020AT is a surface-mount MnO2 tantalum capacitor with a 10 uF capacitance, 20% tolerance, and a 20 VDC voltage rating. Designed for low ESR performance, it features miniature 3216 footprint dimensions with a maximum height of 1.8mm, making it suitable for compact electronic circuits. Constructed with molded, tin-terminal finish, this capacitor offers reliability with a shelf life of 156 weeks and compliance with RoHS standards. It is ideal for applications demanding stable capacitance, low resistance, and high temperature stability.
KEMET T494A106M020AT Tantalum Capacitor Specifications:
- Capacitance: 10 uF
- Capacitance Tolerance: 20%
- Voltage DC: 20 VDC (85°C), 13.4 VDC (125°C)
- Temperature Range: -55°C to +125°C
- Rated Temperature: 85°C
- Dissipation Factor: 10% at 120Hz, 25°C
- Resistance: 3 Ohms at 10kHz, 25°C
- Ripple Current: 142.2 mA (rms, 85°C), 63.2 mA (rms, 125°C)
- Leakage Current: 2 μA at 25°C
- Dimensions: Length 3.2mm ±0.2mm, Width 1.6mm ±0.2mm, Height 1.8mm max
- Footprint: 3216, Tin termination, Molded construction, Low ESR
- Packaging: T&R, 178mm, Quantity: 2000
- RoHS Compliant: Yes
- Series: 1494
- Weight: 58.6mg
Buy the Buy KEMET 10uF T494A106M020AT MnO2 Tantalum Capacitor Online
Purchase the KEMET T494A106M020AT tantalum capacitor online today for your electronic applications. This high-quality SMD component offers 10uF capacitance with 20% tolerance, 20V rating, and low ESR for enhanced performance. Its compact 3216 footprint, molded construction, and tin termination make it ideal for space-constrained designs requiring stability, reliability, and durability. With a shelf life of 156 weeks and RoHS compliance, this capacitor is perfect for power supplies, filtering, and smoothing applications. Get yours now for quick delivery and superior electronic performance.
Order your KEMET Series1494 T494A106M020AT tantalum capacitor today and ensure your electronic projects benefit from reliable low ESR performance.
