KEMET T494B226K020AT Tantalum Capacitor
The T494B226K020AT is a 22 microfarad MnO2 tantalum SMD chip capacitor featuring low ESR and a 10% tolerance. Designed for high reliability, it operates within a -55°C to +125°C temperature range and includes a rated voltage of 20 VDC at 85°C. Its compact 3528 footprint measures approximately 3.5mm in length, 2.8mm in width, and 1.9mm in height, with tin termination for surface-mount assembly. Suitable for demanding electronic applications requiring stable performance and small form factor.
KEMET T494B226K020AT Tantalum Capacitor Specifications:
- Capacitance: 22 uF
- Capacitance Tolerance: 10%
- Voltage DC: 20 VDC at 85°C, 13.4 VDC at 125°C
- Temperature Range: -55°C to +125°C
- Rated Temperature: 85°C
- Dissipation Factor: 8% at 120Hz, 25°C
- Resistance: 3 Ohms (LO0kHz 25°C)
- Ripple Current: 151.2 mA rms at 85°C, 67.2 mA rms at 125°C
- Leakage Current: 4.4 μA for 5 minutes at 25°C
- Dimensions: 3.5mm (L) x 2.8mm (W) x 1.9mm (H)
- Termination: Tin surface-mount
- RoHS Compliant: Yes
- Packaging: T&R, 178mm, Quantity: 2000
- Series: 1494
- Dielectric: MnO2 Tantalum
- Style: SMD Chip
- Features: Low ESR
- MSL: 1, Shelf Life: 156 Weeks
Buy the KEMET Series 1494 MnO2 Tantalum Capacitor: T494B226K020AT
Purchase the KEMET T494B226K020AT tantalum capacitor online today for reliable performance in surface-mount applications. Its low ESR, high reliability, and stable operation over a wide temperature range make it ideal for demanding electronics. With a 22uF capacitance, 20 VDC rating, and advanced MnO2 dielectric, this SMD chip component ensures consistent stability, minimal leakage current, and high durability. Perfect for compact, high-performance circuits needing dependable, long-term operation in diverse environments.
Get KEMET T494B226K020AT today—built for precision, stability, and long-lasting durability in compact electronic devices.
Frequently Asked Questions
Where can I buy KEMET T494B226K020AT?
You can click on the BUY or RFQ button to purchase T494B226K020AT from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part T494B226K020AT?
You can download the T494B226K020AT datasheet or visit the KEMET website for support.
Who is the manufacturer of T494B226K020AT?
KEMET
