KEMET T494C226M016AT tantalum capacitor
The T494 series SMD Tantalum Capacitor from KEMET is ideal for high-volume surface mount applications. It features low ESR, molded design, and complies with EIA standard 535BAAC. The capacitor offers 22uF capacitance with 20% tolerance, rated at 16VDC, and operates within a -55°C to +125°C temperature range. It is encased in a compact 6032 package with a maximum height of 2.8mm, and includes features like tin termination, RoHS compliance, and laser marking. Suitable for automated manufacturing, it ensures reliable performance in demanding electronic circuits.
KEMET T494C226M016AT tantalum capacitor Specifications:
- Capacitance: 22 uF
- Capacitance Tolerance: 20%
- Voltage DC: 16 V
- Temperature Range: -55°C to +125°C
- Rated Temperature: 85°C
- Dissipation Factor: 6% at 120Hz 25°C
- Resistance: 0.35 Ohms (100kHz 25°C)
- Ripple Current: 504.9 mA (rms, 85°C), 224.4 mA (rms, 125°C)
- Leakage Current: 3.5 uA (5 min, 25°C)
- Package: 6032, Max Height: 2.8mm
- Termination: Tin, RoHS compliant
- Series: 1494
- Dielectric: MnO2 Tantalum
- Style: SMD Chip, Molded, Low ESR
- Shelf Life: 156 Weeks
- MSL: 1
- Packaging: T&R, 178mm, Quantity: 500
- Features: Low ESR, Laser-marked, Halogen-free epoxy
- Suitable for automated assembly
Buy the KEMET T494C226M016AT – Reliable Tantalum Capacitor for Industrial Applications
Enhance your electronic designs by ordering the KEMET T494 series tantalum capacitor online. With 22uF capacitance, 16VDC rating, low ESR, and RoHS compliance, this SMD molded component ensures reliable performance in high-volume industrial and automation applications. Its compact 6032 package, maximum height of 2.8mm, and robust construction make it ideal for automated manufacturing. Trust in its extended shelf life, low leakage current, and laser marking for easy identification. Purchase now for consistent quality and efficient supply chain integration.
Order your KEMET SeriesT494C226M016AT tantalum capacitor today and enhance your electronic projects with dependable high-performance components.
Frequently Asked Questions
Where can I buy KEMET T494C226M016AT?
You can click on the BUY or RFQ button to purchase T494C226M016AT from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part T494C226M016AT?
You can download the T494C226M016AT datasheet or visit the KEMET website for support.
Who is the manufacturer of T494C226M016AT?
KEMET
