KEMET T495X336K025ATE175 Tantalum Chip Capacitor
The T495 series capacitors are low ESR, surge-resistant manganese dioxide (MnO2) polarized tantalum chip capacitors designed for high-demand applications requiring excellent surge and ripple current handling. Featuring low ESR, stability under high stress, and resistance to inrush currents, these capacitors operate over -55°C to 125°C and are rated for voltages from 2.5VDC to 50VDC. Available in multiple case sizes, they meet industry standards, undergo accelerated aging, and include optional gold terminations. Ideal for power supply filtering, decoupling, and high-reliability electronics, they offer robust performance and longevity.
KEMET T495X336K025ATE175 Tantalum Chip Capacitor Specifications:
- Capacitance: 33 uF
- Capacitance Tolerance: 10%
- Rated Voltage DC: 16.75 VDC at 85°C
- Temperature Range: -55°C to +125°C
- Dimensions: Length 73mm ±0.3mm, Width 4.3mm ±0.3mm, Height 4mm ±0.3mm
- Leakage Current: 8.3 µA (5min at 25°C)
- Equivalent Series Resistance: 175 mOhms (100kHz, 25°C)
- Dissipation Factor: 4% at 120Hz, 25°C
- Failure Rate: N/A
- Packaging: T&R, 178mm, Quantity: 500
- RoHS Compliant: Yes
- Component Weight: 652.04 mg
- Series: T495
- Dielectric Material: MnO2 Tantalum
- Style: SMD Chip
- Termination: Tin
- Operating Temperature: -55°C to +125°C
- Certifications: Meets industry standards, MSL 1
Buy the KEMET Series T495 MnO2 Tantalum Capacitor: T495X336K025ATE175
Purchase the KEMET T495X336K025ATE175 tantalum chip capacitor online today for high-reliability applications. Designed for demanding power supply circuits, it features low ESR, excellent stability, and high surge current capability. Operating from -55°C to 125°C with a voltage rating of 16.75 VDC, it ensures durability and consistent performance under extreme conditions. Perfect for decoupling, filtering, and high-performance electronic systems. Order now for fast delivery and expert support, ensuring your project benefits from proven quality and robust design.
Get KEMET T495X336K025ATE175 today—built for high surge current resistance and long-lasting reliability.
Frequently Asked Questions
Where can I buy KEMET T495X336K025ATE175?
You can click on the BUY or RFQ button to purchase T495X336K025ATE175 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part T495X336K025ATE175?
You can download the T495X336K025ATE175 datasheet or visit the KEMET website for support.
Who is the manufacturer of T495X336K025ATE175?
KEMET
