KEMET T496C106K025ATE600 SMD Fused Tantalum Capacitor
The T496C106K025ATE600 is a high-reliability SMD MnO2 fused tantalum capacitor designed for industrial applications. It offers a 10 uF capacitance with 10% tolerance, a maximum voltage of 25 VDC, and a low resistance of 600 mOhms. Its compact molded design features tin terminations and an integral fuse for enhanced safety. Suitable for environments requiring stable performance within a -55°C to +125°C temperature range, it ensures durability and consistent operation in demanding electronic circuits.
KEMET T496C106K025ATE600 SMD Fused Tantalum Capacitor Specifications:
- Capacitance: 10 uF
- Capacitance Tolerance: 10%
- Voltage DC: 25 VDC
- Temperature Range: -55°C to +125°C
- Rated Temperature: 85°C
- Dissipation Factor: 6% at 120Hz 25°C
- Resistance: 600 mOhms at 100kHz, 25°C
- Ripple Current: 385.2 mA rms at 85°C, 171.2 mA rms at 125°C
- Leakage Current: 2.5 uA min at 25°C
- Dimensions: Length 6mm ±0.3mm, Width 3.2mm ±0.3mm, Height 2.5mm ±0.3mm
- Termination: Tin
- RoHS Compliant: Yes
- Packaging: T&R, 178mm, 500 pcs
- Series: T496
- Dielectric: MnO2 Tantalum
- Style: SMD Chip
- Features: Integral Fuse
- MSL: 1
- Shelf Life: 156 Weeks
Buy the KEMET T496C106K025ATE600 – Reliable Capacitor for Industrial Applications
Discover the high-quality KEMET T496C106K025ATE600 fused tantalum capacitor, designed for industrial and demanding electronic applications. This 10 uF, 25 VDC component features low resistance, RoHS compliance, and a compact molded design with an integral fuse for enhanced safety. Suitable for circuits requiring stability across -55°C to +125°C temperature ranges, it guarantees durability and reliable performance. Purchase online today to benefit from its excellent characteristics and ensure your electronic systems perform optimally in challenging environments.
Buy KEMET T496C106K025ATE600 high-performance capacitor now and ensure reliable operation in your industrial electronics with its fused design.
Frequently Asked Questions
Where can I buy KEMET T496C106K025ATE600?
You can click on the BUY or RFQ button to purchase T496C106K025ATE600 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part T496C106K025ATE600?
You can download the T496C106K025ATE600 datasheet or visit the KEMET website for support.
Who is the manufacturer of T496C106K025ATE600?
KEMET
