KEMET T499A225K016ATE6K0 Tantalum Capacitor
The product is a high-temperature tantalum capacitor with a capacitance of 2.2 uF, 10% tolerance, rated at 16 VDC, suitable for automotive and industrial applications. It features a molded SMD construction with MnO2 dielectric, operating at temperatures up to 175°C. The component complies with AEC-Q200 standard, making it ideal for automotive electronics. Its dimensions are approximately 3.2mm in length, 1.6mm in width, and maximum height of 1.8mm, with a RoHS-compliant tin termination for reliable soldering and mounting.
KEMET T499A225K016ATE6K0 Tantalum Capacitor Specifications:
- Capacitance: 2.2 μF
- Tolerance: ±10%
- Voltage Rating: 16 VDC
- Temperature Range: -55°C to +175°C
- Dimensions: Length 3.2mm ±0.2mm, Width 1.6mm ±0.2mm, Height Max 1.8mm
- Dielectric: MnO2 Tantalum
- Mounting Type: SMD Chip
- Operating Temperature: 175°C
- RoHS Compliant: Yes
- Qualification: AEC-Q200
- Termination: Tin
- Leakage Current: 0.5 μA at 25°C (5 min)
- Dissipation Factor: 6% at 120Hz, 25°C
- Rated Temperature: 85°C
- Packaging: Tape & Reeled, 178mm, Quantity: 2000
Buy the Buy KEMET Tantalum Capacitor Part Number T499A225K016ATE6K0 Online
Purchase the KEMET T499A225K016ATE6K0 tantalum capacitor online for your automotive and industrial projects. This high-temperature SMD component features a 2.2 microfarad capacitance, rated at 16 volts with a tolerance of ±10%. Designed with MnO2 dielectric and molded construction, it supports operating temperatures up to 175°C. Its compact size and RoHS compliance ensure reliable soldering in space-constrained assemblies. Perfect for automotive electronics requiring high-temp, long-lasting, and high-performance components, ensuring your projects meet strict quality standards.
Get KEMET T499A225K016ATE6K0 today—built for high-temperature durability and reliable performance in demanding electronics.
Frequently Asked Questions
Where can I buy KEMET T499A225K016ATE6K0?
You can click on the BUY or RFQ button to purchase T499A225K016ATE6K0 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part T499A225K016ATE6K0?
You can download the T499A225K016ATE6K0 datasheet or visit the KEMET website for support.
Who is the manufacturer of T499A225K016ATE6K0?
KEMET
