KEMET T520Y337M010ATE015 Polymer Tantalum Capacitor
The T520 series Organic Capacitor (KO-CAP) is a compact, surface mount DC electrolytic component with low ESR, high ripple current, and excellent high-frequency performance. Featuring a conductive polymer cathode, it offers improved capacitance retention at high frequencies, a long lifespan, and is suitable for general DC applications up to 12.8V. Its robust construction ensures reliable operation in DC-DC converters, bulk decoupling, and hold-up circuits. The series combines the benefits of multilayer ceramics and tantalum within a sealed, halogen-free epoxy case, meeting EIA standards for various industrial applications.
KEMET T520Y337M010ATE015 Polymer Tantalum Capacitor Specifications:
- Capacitance: 30 uF
- Capacitance Tolerance: 20%
- Rated Voltage DC: 10 V
- Temperature Range: -55/+105°C
- ESR: 15 mOhms (100kHz 25°C)
- Ripple Current: 4000 mA (rms, 100kHz, 45°C)
- Leakage Current: 330 uA (5 min at 25°C)
- Dimensions: Length 7.3mm ±0.3mm, Width 4.3mm ±0.3mm, Thickness 2.4mm ±0.1mm
- Weight: 493.99 mg
- Shelf Life: 52 Weeks
- Packaging: T&R, 178mm, Quantity: 500 units
- Compliance: RoHS, Halogen-Free
- Construction: Molded, Polymer, Low ESR
- Reliability: 2000 hours at 105°C, Standard case sizes according to EIA standards
Buy the KEMET T520Y337M010ATE015 – Reliable Polymer Tantalum Capacitors for Industrial Applications
Purchase the KEMET T520Y337M010ATE015 polymer tantalum capacitor online today and enjoy reliable performance in high-frequency and industrial power applications. Featuring low ESR, high ripple current capacity, and excellent temperature stability, this capacitor ensures a long operational lifespan suitable for DC-DC converters, decoupling, and hold-up circuits. Its compact surface-mount design adheres to EIA standards and is halogen-free, making it ideal for diverse demanding environments. Secure fast, safe online ordering now to enhance your electronic projects with proven quality and dependable performance.
Order your KEMET Series T520Y337M010ATE015 today and equip your projects with dependable low-ESR polymer capacitors for demanding industrial circuits.
Frequently Asked Questions
Where can I buy KEMET T520Y337M010ATE015?
You can click on the BUY or RFQ button to purchase T520Y337M010ATE015 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part T520Y337M010ATE015?
You can download the T520Y337M010ATE015 datasheet or visit the KEMET website for support.
Who is the manufacturer of T520Y337M010ATE015?
KEMET
