KEMET T521D475M075ATE075 Polymer Tantalum Capacitor
The T521 series organic surface-mount Tantalum Capacitor features a conductive polymer cathode, providing very low equivalent series resistance (ESR) and improved capacitance retention at high frequencies. Combining the benefits of low ESR similar to multilayer ceramic capacitors, high capacitance akin to aluminum electrolytic capacitors, and volumetric efficiency of tantalum in a compact package, this capacitor offers long operational life and high ripple current capability without the drawbacks of liquid electrolytes. Designed for higher voltage applications than the T520 series, it is highly reliable and suitable as an alternative to traditional liquid electrolytic capacitors. Key features include volumetric efficiency, temperature stability, high ripple current, long-term reliability, surge current testing, low profile design, and halogen-free epoxy construction. Market demand has extended lead times, and delivery dates may vary; this product is exempt from discounts.
KEMET T521D475M075ATE075 Polymer Tantalum Capacitor Specifications:
- Capacitance: 4.7 uF
- Capacitance Tolerance: 20%
- Rated Voltage: 75 VDC
- Temperature Range: -55°C to +125°C
- Rated Temperature: 105°C
- Dimensions: Length 7.3mm +/-0.3mm, Width 4.4mm +/-0.1mm, Height Max 3.1mm
- Resistance: 75 mOhms (100kHz 25°C)
- Ripple Current: 2050 mA (rms, 85°C), 512.5 mA (rms, 125°C)
- Leakage Current: 35.3 μA (5 min at 25°C)
- Dissipation Factor: 10% at 120Hz 25°C
- Termination: Tin
- Packaging: T&R, 178mm reel, Quantity: 500
- Compliance: RoHS Yes, Halogen-free
- Shelf Life: 52 Weeks
- MSL: 3
- Application: Suitable for high-voltage, high-reliability electronic circuits
Buy the KEMET T521D475M075ATE075 – Reliable Polymer Tantalum for Industrial Applications
Enhance your electronic designs with the KEMET Polymer Tantalum Capacitor. Featuring low ESR, high ripple current, and excellent reliability, this 75V, 4.7uF capacitor is ideal for high-voltage and high-frequency applications. Its compact SMD form factor, temperature stability, and long operational life make it perfect for demanding environments. Order online today to ensure fast delivery of this advanced, RoHS-compliant component. Make your projects more reliable with this high-quality, environmentally friendly capacitor designed for optimal performance in industrial electronics.
Order your KEMET Series T521D475M075ATE075 today and give your projects the dependable quality they deserve with high ripple current capability and long life.
Frequently Asked Questions
Where can I buy KEMET T521D475M075ATE075?
You can click on the BUY or RFQ button to purchase T521D475M075ATE075 from an authorized KEMET distributor.
How do I troubleshoot issues or seek technical support for part T521D475M075ATE075?
You can download the T521D475M075ATE075 datasheet or visit the KEMET website for support.
Who is the manufacturer of T521D475M075ATE075?
KEMET
