KYOCERA AVX SCMR22J105SSBA0 Supercapacitor Module
Series-connected supercapacitor modules offering high pulse power, low ESR, and low leakage current, ideal for energy harvesting, backup, and pulse applications. Designed with moisture resistant plastic casing and tested for cycle life, high temperature, vibration, and humidity performance. Suitable for camera flash, GSM/GPRS pulse, UPS, wireless alarms, remote metering, and toys. Operates between -40°C to +85°C with various voltage ratings, providing extended backup power, quick energy discharge, and reliable long-term stability in industrial and consumer electronics.
KYOCERA AVX SCMR22J105SSBA0 Supercapacitor Module Specifications:
- Capacitance: 0.33F to 15F depending on model
- Dimensions: Diameter 8mm to 16mm, Length 14mm to 33mm
- Voltage Rating: 4.6V, 5.4V, 6.0V, 7.5V, 9.0V, 10V, 12.5V, 16V, 18V, 22.5V, 32.75V, 75V
- Maximum Operating Temperature: -40°C to +85°C
- Temperature Range for Standard Use: -40°C to +65°C (most models), -40°C to +85°C (higher voltage types)
- Leakage Current: Low, within manufacturer specifications
- ESR (Equivalent Series Resistance): Max values depend on model but typically below 0.3Ω at 1kHz
- Pulse Power Capability: High, suitable for rapid discharge applications
- Soldering: Compatible with hand, reflow, and wave soldering (except for radial wrap types)
- Certifications: RoHS, UL810A, Reach Compliant, Halogen Free
- Storage Environment: Avoid high humidity, temperature above 70°C, corrosive environments, dust, shock, and vibration
- Mechanical: Available in shrink wrap type with straight or bent leads for various circuit integration
- Testing Standards: IEC capacitance test, ESR measurement at 1000Hz, life cycle, temperature cycling and vibration testing
Buy the Buy Manufacturer SuperCapacitor Part Number SCMR22J105SSBA0 Online
Order the high-quality supercapacitor module online today for reliable energy storage and rapid pulse power. Perfect for backup systems, energy harvesting, and industrial applications. Designed with moisture resistant casing and tested for extreme conditions, ensuring durability and performance. Whether you need a compact solution for consumer electronics or industrial backup power, this supercapacitor offers excellent pulse handling, low leakage, and extended life span. Act now and enhance your device's energy efficiency and resilience with our trusted online ordering options.
Get Manufacturer SuperCapacitor SCMR22J105SSBA0 today—built for high pulse power, low ESR, and long-lasting durability.
Frequently Asked Questions
Where can I buy KYOCERA AVX SCMR22J105SSBA0?
You can click on the BUY or RFQ button to purchase SCMR22J105SSBA0 from an authorized KYOCERA AVX distributor.
How do I troubleshoot issues or seek technical support for part SCMR22J105SSBA0?
You can download the SCMR22J105SSBA0 datasheet or visit the KYOCERA AVX website for support.
Who is the manufacturer of SCMR22J105SSBA0?
KYOCERA AVX
